| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | BF1493 | PEDAL (4) | 1 | ||||
| ? | VJ4023 | RING, RETAINER (1)/(2)/(4) | 3 | ||||
| ? | VE3517 | ROLLER (2)/(4) | 1 | ||||
| ? | BF1494 | LEVER, TREADLE (4) | 1 | ||||
| ? | XA3743 | HARNESS, WIRE (3)/(4) | 1 | ||||
| ? | VE7634 | CLAMP, WIRE (3)/(4) | 2 | ||||
| ? | VE4213 | SCREW, PAN HEAD (3)/(4) | 2 | ||||
| ? | VC9049 | CAPSCREW - 5/16" - 18NC X 5/8" (6) | 4 | ||||
| ? | BF1495 | COVER | 1 | ||||
| ? | PIN, TREADLE (1)/(4)/(5) | 1 | |||||
| ? | VE3504 | BUSHING (1)/(4) | 2 | ||||
| ? | VE3510 | BUSHING (1)/(4) | 2 | ||||
| ? | SENSOR (3)/(4)/(5) | 1 | |||||
| ? | VE7551 | PIN (4) | 1 | ||||
| ? | SC4174 | LOCKWASHER - 5/16" (6) | 4 | ||||
| ? | SPRING (4)/(5) | 2 | |||||
| ? | BF1492 | DRIVE SHAFT, POTENTIOMETER (4) | 1 | ||||
| ? | VE7557 | BUSHING (4) | 2 | ||||
| ? | BF1355 | PLATE, BASE | 1 | ||||
| ? | VE7638 | PIN, ROLLER (2)/(4) | 1 | ||||
| ? | VE7556 | WASHER, THRUST - OUTER (4) | 2 | ||||
| ? | VE3522 | MACHINE SCREW (4) | 2 | ||||
| ? | VE7549 | NOTE: (1) INCLUDED IN VE7549 TREADLE PIN KIT. | |||||
| ? | VE7561 | (2) INCLUDED IN VE7561 ROLLER KIT. | |||||
| ? | XA3744 | (3) INCLUDED IN XA3744 SENSOR KIT. | |||||
| ? | XA4077 | (4) INCLUDED IN XA4077 UPPER SERVICE ASSEMBLY KIT. | |||||
| ? | (5) NOT SERVICED SEPARATELY. | ||||||
| ? | (6) NOT INCLUDED IN ASSEMBLY. |
