| Наименование | Страница | Код страницы |
|---|---|---|
| STEERING COLUMN INSTALLATION | 176 | 55652 |
| STEERING COLUMN ASSEMBLY XB8878 | 178 | 56116 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | PC0683 | WHEEL, STEERING | 1 | ||||
| ? | PC1621 | BUTTON, HORN | 1 | ||||
| ? | XB8879 | STEERING COLUMN ASSEMBLY (SEE FIG 55652) | 1 | 55652 | |||
| ? | XB8878 | • COLUMN, STEERING (SEE INDEX) | 1 | 56116 | |||
| ? | PC1709 | • MULTI-FUNCTION SWITCH ASSEMBLY | 1 | ||||
| ? | WB3105 | • FLAT WASHER - M7 | 2 | ||||
| ? | WB3104 | • FLAT WASHER - M5 | 2 | ||||
| ? | WB3103 | • LOCKWASHER - M5 | 2 | ||||
| ? | WB3102 | • CAPSCREW - M5 X .8 X 25 | 2 | ||||
| ? | 08021-00400 | • CONNECTOR | 1 | ||||
| ? | VZ4843 | • TYRAP | 1 | ||||
| ? | MM0604 | CAPSCREW - M10 X 1.50 X 20 | 4 | ||||
| ? | MM0713 | FLAT WASHER - M10 | 4 | ||||
| ? | MM0471 | LOCKWASHER - M10 | 4 |
