| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | EJ8859 | REAR SUSPENSION ASSEMBLY (1) | 1 | ||||
| ? | VM0313 | • PLUG, O-RING BOSS - 1/4" (2) | 3 | ||||
| ? | R1073 | • DRIVE SCREW - #6 - 32NC X 3/16" | 8 | ||||
| ? | WA2892 | • PLATE, HIGH PRESSURE CYLINDER DANGER | 1 | ||||
| ? | EJ8866 | • HOUSING | 1 | ||||
| ? | VM2202 | • PLUG, VENT (2) | 1 | ||||
| ? | VM0314 | • PLUG, O-RING BOSS - 3/8" (2) | 1 | ||||
| ? | PB2194 | • CHARGING VALVE ASSEMBLY (2)/(3) | 1 | ||||
| ? | TD7179 | • • CORE, VALVE | 1 | ||||
| ? | TR9993 | • • CAP, VALVE | 1 | ||||
| ? | TF1144 | • • O-RING (VALVE BODY) | 1 | ||||
| ? | WA0052 | • • O-RING (VALVE STEM) | 1 | ||||
| ? | VD5076 | • GASKET (2)/(3) | 1 | ||||
| ? | TZ8637 | • PLUG, SENSOR | 1 | ||||
| ? | 562-50-32270 | • RING, WEAR (2) | 1 | ||||
| ? | 581-50-21910 | • O-RING (2) | 1 | ||||
| ? | 07001-05330 | • RING, BACKUP (2) | 1 | ||||
| ? | 581-50-11180 | • BUSHING (2) | 1 | ||||
| ? | 562-50-36150 | • FLANGE | 1 | ||||
| ? | 581-50-11290 | • PACKING (2) | 1 | ||||
| ? | 581-50-11280 | • BUSHING (2) | 1 | ||||
| ? | 562-50-36220 | • RETAINER | 1 | ||||
| ? | 581-50-21252 | • SEAL (2) | 1 | ||||
| ? | 562-50-36210 | • PLATE | 1 | ||||
| ? | 01011-81825 | • CAPSCREW | 18 | ||||
| ? | 01643-31845 | • WASHER | 18 | ||||
| ? | EJ8861 | • PISTON | 1 | ||||
| ? | PC1006 | CLAMP | 2 | ||||
| ? | 562-50-36191 | SHIELD | 1 | ||||
| ? | NOTE: NS = NOT SHOWN | ||||||
| ? | VJ3911 | • OIL, SUSPENSION (5 GALLON CAN) | 2 | ||||
| ? | VJ5925 | • OIL, SUSPENSION - COLD WEATHER (5 GALLON CAN) (4) | 2 | ||||
| ? | AK3761 | • ADDITIVE, OIL (5 GALLON CAN) | 1 | ||||
| ? | NOTE: (1) NOT SERVICED AS AN ASSEMBLY. ORDER NEXT HIGHER | ||||||
| ? | LEVEL. | ||||||
| ? | AK4941 | (2) INCLUDED IN AK4941 REAR SUSPENSION OVERHAUL KIT. | |||||
| ? | RK1887 | (3) INCLUDED IN RK1887 CHARGING VALVE KIT. | |||||
| ? | (4) EJ8859 DOES NOT INCLUDE COLD WEATHER SUSPENSION | ||||||
| ? | OIL. VJ5925 MUST BE ORDERED SEPARATELY. |
