Содержание Dump Trucks Komatsu AFE47-GP 730E S/N A30628 - A30629 & A30632 KUMBA KOLOMELA(AFE47-GP)
RETARDING GRID ASSEMBLY - 7 STEP 4/4 PC2158(660 : 64250)
Номер на схеме Каталожный номер Название Количество Детали
? VE4655 FLAT WASHER - #10
? VE4601 LOCKWASHER - #10
? SF2755 NUT - #10 - 32NF
? GE0220 SUPPORT, MODULE 7
? GE0219 SUPPORT, MODULE 7
? BF4452 MODULE 7
? XA2748 BUS BAR - 1/2" THICK 4
? XA2754 BUS BAR - INSULATED 1
? GE0044 FLAT WASHER - 21/32"
? VC1390 LOCKWASHER - 5/8" 1
? GE0045 NUT - 1/2" - 13NC
? XA2755 BUS BAR - INSULATED 2
? XA2476 GRID, RETARDING 2
? GE0038 SPACER 18
? XA2745 BUS BAR - INSULATED 5
? XA2746 BUS BAR - INSULATED 5
? GE0042 WASHER - 5/8" (NARROW)
? GE0023 INSULATOR 28
? XA2741 NUT - 5/8" - 11NC
? XA2475 GRID, RETARDING 12
? GE0013 LOUVER ASSEMBLY 4
? XA2739 COVER - 36" X 24" 2
? XA2740 COVER ASSEMBLY 2
? XA2738 COVER - 36" X 20" 2
? GE0014 COVER W/ CUTOUTS 2
