| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | EF8177 | BRACKET | 1 | ||||
| ? | MM0605 | CAPSCREW - M10 X 1.50 X 25 | 9 | ||||
| ? | MM0471 | LOCKWASHER - M10 | 15 | ||||
| ? | WB0430 | FITTING, BULKHEAD - STRAIGHT | 8 | ||||
| ? | WB0427 | FITTING, BULKHEAD | 2 | ||||
| ? | WB0432 | FITTING, BULKHEAD | 1 | ||||
| ? | WB1304 | CLAMP, CUSHION - 9/16" | 2 | ||||
| ? | EF8174 | CLAMP | 2 | ||||
| ? | TY8375 | SPACER | 6 | ||||
| ? | WB3092 | CLAMP, CUSHION - 7/8" | 8 | ||||
| ? | WB1308 | CLAMP, CUSHION - 1 1/16" | 2 | ||||
| ? | MM0461 | FLAT WASHER - M10 | 6 | ||||
| ? | MM0178 | NUT - M10 X 1.50 | 6 | ||||
| ? | EF9801 | FLAP, RUBBER | 1 | ||||
| ? | MM0594 | CAPSCREW - M8 X 1.25 X 25 | 3 | ||||
| ? | MM0460 | FLAT WASHER - M8 | 4 | ||||
| ? | MM0470 | LOCKWASHER - M8 | 4 | ||||
| ? | MM0177 | NUT - M8 X 1.25 | 4 |
