Номер на схеме |
Каталожный номер |
Название |
Количество |
Детали |
|
|
|
? |
TD1548 |
CAPSCREW - 1/4" - 20NC X 5/8" |
4 |
|
|
|
|
? |
SP8417 |
FLAT WASHER - 1/4" |
4 |
|
|
|
|
? |
DC3584 |
LOCKWASHER - 1/4" |
4 |
|
|
|
|
? |
EL4788 |
BOX, JUNCTION (SEE INDEX) |
1 |
|
55739 |
|
|
? |
WB0983 |
GRIP, CORD |
1 |
|
|
|
|
? |
VZ2691 |
LOCKNUT, CONDULET - 1 1/4" |
1 |
|
|
|
|
? |
EK7638 |
HARNESS, CAB/JUNCTION BOX |
1 |
|
|
|
|
? |
TC1565 |
CLAMP, VINYL - 15/16" |
5 |
|
|
|
|
? |
VN9907 |
CLAMP, VINYL - 5/8" |
3 |
|
|
|
|
? |
MM0461 |
FLAT WASHER - M10 |
3 |
|
|
|
|
? |
MM0471 |
LOCKWASHER - M10 |
3 |
|
|
|
|
? |
MM0178 |
NUT - M10 X 1.50 |
3 |
|
|
|
|
? |
WA5460 |
CLAMP, HEAVY DUTY |
1 |
|
|
|
|
? |
EJ4037 |
COVER, PLATE CONNECTOR HOLE |
1 |
|
|
|
|
? |
PB9829 |
SCREW, PAN - M6 X 1.00 X 16 |
12 |
|
|
|
|
? |
SM6073 |
PLATE, CONNECTOR |
1 |
|
|
|
|
? |
SM6068 |
PLATE, MOUNTING |
1 |
|
|
|
|
? |
SM6066 |
COVER, BENT PLATE |
1 |
|
|
|
|
? |
|
(NOT USED THIS APPLICATION) |
|
|
|
|
|
? |
MM0580 |
CAPSCREW - M6 X 1.00 X 14 |
3 |
|
|
|
|
? |
MM0016 |
CAPSCREW - M8 X 1.25 X 16 |
2 |
|
|
|
|
? |
MM0460 |
FLAT WASHER - M8 |
2 |
|
|
|
|
? |
PB9862 |
CAP, PROTECTIVE METAL |
1 |
|
|
|
|
? |
SM2117 |
PLATE, NUT CONNECTOR |
1 |
|
|
|
|
? |
WA5641 |
SCREW, MACHINE - #4 - 40NC X 3/8" |
4 |
|
|
|
|
? |
SF0542 |
SCREW, MACHINE - #4 - 40NC X 5/16" |
1 |
|
|
|
|
? |
VD7129 |
LOCKWASHER - #4 |
1 |
|
|
|
|
? |
VN9717 |
NUT - #4 - 40NC |
1 |
|
|
|
|
? |
EJ3060 |
PAYLOAD METER III ASSEMBLY |
1 |
|
|
|
|
? |
VC8762 |
CAPSCREW - 3/8" - 16NC X 1 1/2" |
4 |
|
|
|
|
? |
TR4436 |
FLAT WASHER - 3/8" |
4 |
|
|
|
|
? |
TC1231 |
LOCKWASHER - 3/8" |
4 |
|
|
|
|
? |
SM5049 |
NUT, SPRING - 3/8" - 16NC |
4 |
|
|
|
|
? |
MM0401 |
CAPSCREW - M8 X 1.25 X 90 |
4 |
|
|
|
|
? |
MM0703 |
FLAT WASHER - M8 |
4 |
|
|
|
|
? |
VZ1368 |
GRIP, CORD |
1 |
|
|
|
|
? |
EJ4036 |
ADAPTER |
1 |
|
|
|
|
? |
SM0724 |
GASKET |
1 |
|
|
|
|
? |
WA5643 |
SCREW, MACHINE |
4 |
|
|
|
|
? |
EJ9252 |
ADAPTER, SPEEDOMETER/CAB HARNESS |
1 |
|
|
|
|
? |
EK7639 |
ATTENUATOR ASSEMBLY |
1 |
|
|
|
