| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | WB2698 | STRIP, CIRCUIT | 1 | ||||
| ? | VM2951 | SCREW, SELF-TAPPING - #6 - 32NC X 5/16" | 2 | ||||
| ? | EH9772 | CABLE | 1 | ||||
| ? | CH2156 | CABLE - 7J1LS | 1 | ||||
| ? | CH2155 | CABLE - 7J1RS | 1 | ||||
| ? | CH3198 | CABLE - 7J7 | 1 | ||||
| ? | CH3966 | CABLE - 7J1R | 1 | ||||
| ? | CH3967 | CABLE - 7J1L | 1 | ||||
| ? | CH3199 | CABLE - 7J8 | 1 | ||||
| ? | CH3197 | CABLE - 7J1 | 1 | ||||
| ? | CH3901 | CABLE - 7GA2 | 1 | ||||
| ? | CH4913 | CABLE - 7J4 | 1 | ||||
| ? | CH2599 | CABLE - 74 | 1 | ||||
| ? | CH3964 | CABLE - 7J2 | 1 | ||||
| ? | ED8936 | CLEAT, CABLE | 4 | ||||
| ? | TN2590 | SPACER, HOSE | 4 | ||||
| ? | EB9886 | STUD, THREADED - M16 X 2.00 | 2 | ||||
| ? | MM0464 | FLAT WASHER - M16 | 2 | ||||
| ? | MM0474 | LOCKWASHER - M16 | 2 | ||||
| ? | MM0181 | NUT - M16 X 2.00 | 2 | ||||
| ? | VA0609 | SPACER | 1 | ||||
| ? | ED8937 | CLEAT, CABLE | 2 | ||||
| ? | CH3965 | CABLE - 7GA1 | 1 | ||||
| ? | CH3911 | CABLE - 7GA1 | 1 | ||||
| ? | CH2593 | CABLE - 71J | 1 | ||||
| ? | CH2595 | CABLE - 74AA | 1 | ||||
| ? | CH2596 | CABLE - 75XX | 1 | ||||
| ? | TV3555 | BUTTON, PLUG - 1 3/8" DIA HOLE | 4 | ||||
| ? | CH2591 | CABLE - 74G | 1 | ||||
| ? | CH2594 | CABLE - 74D | 1 | ||||
| ? | CH4912 | CABLE - 7J9 | 1 | ||||
| ? | TR9441 | CLAMP, VINYL - 1 1/4" | 1 | ||||
| ? | MM0460 | FLAT WASHER - M8 | 9 | ||||
| ? | MM0470 | LOCKWASHER - M8 | 9 | ||||
| ? | MM0177 | NUT - M8 X 1.25 | 4 | ||||
| ? | ED5353 | COVER | 1 | ||||
| ? | ED2922 | GASKET | 1 | ||||
| ? | MM0335 | SCREW, MACHINE - M3.5 X .6 X 12 (PAN HD) | 4 | ||||
| ? | 30289R1 | FLAT WASHER - M4 | 4 | ||||
| ? | MM0377 | LOCKWASHER - M3.5 | 4 | ||||
| ? | MM0371 | NUT - M3.5 X .6 | 4 | ||||
| ? | EG0008 | HARNESS, ACCUMULATOR PRESSURE SWITCH | 1 | ||||
| ? | EH7354 | HARNESS, ENGINE/CONTROL CABINET | 1 | ||||
| ? | EH7373 | HARNESS, CAB/CONTROL CABINET | 1 | ||||
| ? | EJ6351 | HARNESS, CAB POWER | 1 | ||||
| ? | VN9908 | CLAMP, VINYL - 1" | 1 | ||||
| ? | TC6058 | CLAMP, VINYL - 1 1/2" | 2 | ||||
| ? | EH6011 | HARNESS, CAB/CONTROL CABINET | 1 | ||||
| ? | ED3913 | CABLE | 1 | ||||
| ? | VW4875 | BUTTON, PLUG - 1 3/4" DIA HOLE | 2 | ||||
| ? | EJ5791 | HARNESS, ENGINE/CONTROL CABINET | 1 | ||||
| ? | EK4130 | HARNESS, CAB/SYSTEM DIAGHRAM | 1 | ||||
| ? | TF6924 | CLAMP, VINYL - 1 3/4" | 1 | ||||
| ? | EJ5653 | HARNESS, L.H. DECK JUMPER | 1 | ||||
| ? | EJ5726 | HARNESS, CONTROL CABINET JUNCTION BOX | 1 | ||||
| ? | SG7854 | BUTTON, PLUG - 5/8" DIA HOLE | 1 | ||||
| ? | EM3389 | PLATE, MOUNTING | 1 | ||||
| ? | ED3408 | GASKET | 1 | ||||
| ? | MM0593 | CAPSCREW - M8 X 1.25 X 20 | 5 | ||||
| ? | EH7356 | HARNESS, LEFT FRAME RAIL | 1 | ||||
| ? | EJ8667 | HARNESS - RIGHT FRAME RAIL | 1 | ||||
| ? | NOTE: NS = NOT SHOWN | ||||||
| ? | EG0002 | HARNESS, EXTENDED RANGE RETARDING | 1 | ||||
| ? | WA4649 | CLAMP, VINYL - 11/16" | 4 | ||||
| ? | VN2971 | BUTTON, PLUG - 1 1/2" DIA HOLE | 4 | ||||
| ? | VZ1807 | BUTTON, PLUG - 13/16" DIA HOLE | 2 | ||||
| ? | HD7569 | BUTTON, PLUG - 3/8" DIA HOLE | 1 |
