Содержание Excavators Komatsu PC400-7(-50) S/N Y400001-UP(ZEPB901)
TRACK FRAME (VARIABLE GAUGE) (GREASE BATH AND STEP)(|ZR00075 : |ZR00075)
Номер на схеме Каталожный номер Название Количество Детали
? 208-30-61220 COVER 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 1
Field_6: X21-1379120
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 205-30-71181 COVER 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 2
Field_6: X21-1379120
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 205-30-71191 GASKET 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 3
Field_6: X21-1379120
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 01580-11008 NUT 2
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 4
Field_6: X21-1379120
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 01643-31032 WASHER 2
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 5
Field_6: X21-1379120
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 207-30-51260 SEAL 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 6
Field_6: X21-1379120
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 205-30-71171 SEAL 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 7
Field_6: X21-1379120
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 208-30-75710 BRACKET 4
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 8
Field_6: X21-1379120
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 01010-81640 BOLT 16
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 9
Field_6: X21-1379120
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 01643-31645 WASHER 16
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 10
Field_6: X21-1379120
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 208-30-75390 COLLAR 20
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 11
Field_6: X21-1379120
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 208-30-12130 BOLT 20
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 12
Field_6: X21-1379120
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
