Содержание Excavators Komatsu PC400-7(-50) S/N Y400001-UP(ZEPB901)
TRACK FRAME (VARIABLE GAUGE) (FULL ROLLER GUARD) (WITH UNDER COVER) (SN )(|ZR00042 : |ZR00042)
Номер на схеме Каталожный номер Название Количество Детали
? 208-30-75611 FRAME 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 1
Field_6: X21-1007400
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 208-30-75610 FRAME 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 2
Field_6: X21-1007400
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 208-30-75142 FRAME, L.H. 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 3
Field_6: X21-1007400
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 208-30-75E10 • BRACKET\((WELDED)\) 2
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 4
Field_6: X21-1007400
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 208-30-75152 FRAME, R.H. 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 5
Field_6: X21-1007400
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 208-30-75E10 • BRACKET\((WELDED)\) 2
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 6
Field_6: X21-1007400
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 208-30-75181 PLATE 2
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 7
Field_6: X21-1007400
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 01010-81225 BOLT 4
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 8
Field_6: X21-1007400
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 01643-31232 WASHER 4
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 9
Field_6: X21-1007400
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 208-30-75390 COLLAR 16
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 10
Field_6: X21-1007400
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 208-30-12130 BOLT 16
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 11
Field_6: X21-1007400
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 208-30-12160 PLATE 4
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 12
Field_6: X21-1007400
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 208-30-31650 COLLAR 8
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 13
Field_6: X21-1007400
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 01011-63030 BOLT 8
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 14
Field_6: X21-1007400
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 01643-33080 WASHER 8
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 15
Field_6: X21-1007400
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 07049-03949 PLUG 8
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 16
Field_6: X21-1007400
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 208-30-77110 GUARD 2
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 17
Field_6: X21-1007400
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 208-30-77120 GUARD 2
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 18
Field_6: X21-1007400
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 208-30-77130 GUARD 2
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 19
Field_6: X21-1007400
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 208-30-77140 GUARD 2
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 20
Field_6: X21-1007400
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 01010-62455 BOLT 24
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 21
Field_6: X21-1007400
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 01643-32460 WASHER 24
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 22
Field_6: X21-1007400
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 421-975-1230 BOLT 16
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 23
Field_6: X21-1007400
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 01643-32460 WASHER 32
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 24
Field_6: X21-1007400
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 01580-12419 NUT 16
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 25
Field_6: X21-1007400
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 150-30-15553 SPACER 16
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 26
Field_6: X21-1007400
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:

Excavators Komatsu / PC400-7(-50) S/N Y400001-UP(ZEPB901) / TRACK FRAME (VARIABLE GAUGE) (FULL ROLLER GUARD) (WITH UNDER COVER) (SN )(|ZR00042 : |ZR00042)
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
