| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | HA5564 | HOSE, SUPPLY (TO JUNCTION BLOCK) | 2 | ||||
| ? | WB0538 | FITTING, O-RING - 45 DEG (AT JUNCTION BLOCK) | 2 | ||||
| ? | TZ0231 | TUBE | 2 | ||||
| ? | WB0418 | FITTING, TEE | 1 | ||||
| ? | WA4704 | CLAMP, HYDRA-ZORB | 11 | ||||
| ? | TZ0230 | TUBE | 1 | ||||
| ? | WB0403 | FITTING, UNION | 1 | ||||
| ? | C1602 | CAPSCREW - 3/8" - 16NC X 1" | 4 | ||||
| ? | TZ7334 | TUBE | 2 | ||||
| ? | TZ7333 | BAR, FLAT | 4 | ||||
| ? | C0312 | LOCKWASHER - 3/8" | 8 | ||||
| ? | TR4436 | FLAT WASHER - 3/8" | 4 | ||||
| ? | C1521 | NUT - 3/8" - 16NC | 4 | ||||
| ? | 424243 | CLAMP | 4 | ||||
| ? | TZ7335 | TUBE | 2 | ||||
| ? | WB0505 | FITTING, O-RING - 90 DEG | 2 | ||||
| ? | TY2147 | BLOCK, JUNCTION | 2 | ||||
| ? | WB0533 | FITTING, O-RING | 4 | ||||
| ? | C8558 | CAPSCREW - 3/8" - 16NC X 3 1/4" | 8 | ||||
| ? | DF3042 | FLAT WASHER - 3/8" | 4 | ||||
| ? | VW5169 | SPACER | 4 | ||||
| ? | WB0581 | FITTING, O-RING - STRAIGHT ADAPTOR | 4 | ||||
| ? | WA4871 | CLAMP | 2 | ||||
| ? | WA4875 | CLAMP | 2 | ||||
| ? | TZ7336 | TUBE | 2 |
