| Наименование | Страница | Код страницы |
|---|---|---|
| HOIST CYLINDER ASSEMBLY (TY5936) | 374 | 14455 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | TY7320 | PIN, UPPER HOIST | 2 | ||||
| ? | VA0538 | BUSHING, BALL | 1 | ||||
| ? | VN9346 | RETAINER RING | 2 | ||||
| ? | VN9225 | CAPSCREW - 1 1/2" - 6NC X 8" | 2 | ||||
| ? | VM5655 | LOCKNUT - 1 1/2" - 6NC | 2 | ||||
| ? | TY5936 | HOIST CYLINDER ASSM (SEE INDEX) | 1 | 14455 | |||
| ? | TY3578 | SHAFT, HOIST BEARING | 1 | ||||
| ? | VN9351 | RETAINER RING | 2 | ||||
| ? | VA4707 | RETAINER PLATE | 1 | ||||
| ? | TX3664 | LOCKING PLATE | 1 | ||||
| ? | C7645 | CAPSCREW - 3/4" - 10NC X 1 1/2" | 3 | ||||
| ? | PB0027 | BUSHING, BALL | 1 | ||||
| ? | VA5501 | SPACER, BEARING | 1 | ||||
| ? | (QUANTITIES SHOWN ARE FOR ONE SIDE ONLY) |
