| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 421-06-44230 | Cover | 1 | SN: 10001- KIT-FLAG: _- SCC: SERIALNO: 10001- |
|||
| ? | 01010-D1020 | Bolt | 4 | SN: 10001- KIT-FLAG: _- SCC: SERIALNO: 10001- |
|||
| ? | 01643-71032 | Washer | 4 | SN: 10001- KIT-FLAG: _- SCC: SERIALNO: 10001- |
|||
| ? | 01580-11008 | Nut | 2 | SN: 10001- KIT-FLAG: _- SCC: SERIALNO: 10001- |
|||
| ? | 20Y-54-11611 | Stopper | 2 | SN: 10001- KIT-FLAG: _- SCC: SERIALNO: 10001- |
|||
| ? | 421-06-44510 | Cover | 1 | SN: 10001- KIT-FLAG: _- SCC: SERIALNO: 10001- |
|||
| ? | 416-09-12230 | • Hinge, Welded | 1 | SN: 10001- KIT-FLAG: _- SCC: SERIALNO: 10001- |
|||
| ? | 01010-81025 | Bolt | 2 | SN: 10001- KIT-FLAG: _- SCC: SERIALNO: 10001- |
|||
| ? | 01643-31032 | Washer | 2 | SN: 10001- KIT-FLAG: _- SCC: SERIALNO: 10001- |
|||
| ? | 424-06-44250 | Plate | 1 | SN: 10001- KIT-FLAG: _- SCC: SERIALNO: 10001- |
|||
| ? | 421-06-24230 | Bar | 1 | SN: 10001- KIT-FLAG: _- SCC: SERIALNO: 10001- |
|||
| ? | 01641-20812 | Washer | 2 | SN: 10001- KIT-FLAG: _- SCC: SERIALNO: 10001- |
|||
| ? | 04050-12015 | Pin, Cotter | 1 | SN: 10001- KIT-FLAG: _- SCC: SERIALNO: 10001- |
|||
| ? | 421-09-12322 | Holder | 1 | SN: 10001- KIT-FLAG: _- SCC: SERIALNO: 10001- |
|||
| ? | 01220-40408 | Screw | 3 | SN: 10001- KIT-FLAG: _- SCC: SERIALNO: 10001- |
|||
| ? | 01220-40408 | Screw | 2 | SN: 10001- KIT-FLAG: _- SCC: SERIALNO: 10001- |
|||
| ? | 01641-20405 | Washer | 5 | SN: 10001- KIT-FLAG: _- SCC: SERIALNO: 10001- |
|||
| ? | (421-06-44581) | Pipe(Battery Box,Battery Box Wiring Harness) | SN: - KIT-FLAG: _- SCC: SERIALNO: |
E0120-008005 | |||
| ? | (421-06-44581) | Pipe(Battery Box,Battery Box Wiring Harness) | SN: - KIT-FLAG: _- SCC: SERIALNO: |
E0120-010006 | |||
| ? | (421-06-44581) | Pipe(Battery Box,Battery Box Wiring Harness,With Battery Disconnect Switch) | SN: - KIT-FLAG: _- SCC: SERIALNO: |
E0120-013006 | |||
| ? | (421-06-41261) | Wiring Harness(Battery Box,Rear Combination Lamp) | SN: - KIT-FLAG: _- SCC: SERIALNO: |
E0120-008004 | |||
| ? | (421-06-41261) | Wiring Harness(Battery Box,Rear Combination Lamp) | SN: - KIT-FLAG: _- SCC: SERIALNO: |
E0120-010004 | |||
| ? | (421-06-41261) | Wiring Harness(Battery Box,Rear Combination Lamp) | SN: - KIT-FLAG: _- SCC: SERIALNO: |
E0120-013004 |
