| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 702-22-01010 | VALVE,PILOT | 1 | Field_1: Field_2: Y221319 Field_3: Field_4: Field_5: 1 Field_6: X21-2465630 Field_7: CAB U.A/C,MW,3G,1ATT |
|||
| ? | • VALVE BODY | 1 | Field_1: Field_2: Y221319 Field_3: Field_4: C1 Field_5: 2 Field_6: X21-2465630 Field_7: CAB U.A/C,MW,3G,1ATT |
||||
| ? | • VALVE | 4 | Field_1: Field_2: Y221319 Field_3: Field_4: C1 Field_5: 3 Field_6: X21-2465630 Field_7: CAB U.A/C,MW,3G,1ATT |
||||
| ? | 702-16-51140 | • SHIM{T=0.30MM} | 4 | Field_1: Field_2: Y221319 Field_3: Field_4: Field_5: 4 Field_6: X21-2465630 Field_7: CAB U.A/C,MW,3G,1ATT |
|||
| ? | 702-16-53420 | • SPRING | 4 | Field_1: Field_2: Y221319 Field_3: Field_4: Field_5: 5 Field_6: X21-2465630 Field_7: CAB U.A/C,MW,3G,1ATT |
|||
| ? | 702-16-53140 | • RETAINER | 4 | Field_1: Field_2: Y221319 Field_3: Field_4: Field_5: 6 Field_6: X21-2465630 Field_7: CAB U.A/C,MW,3G,1ATT |
|||
| ? | 702-16-54420 | • SPRING | 4 | Field_1: Field_2: Y221319 Field_3: Field_4: Field_5: 7 Field_6: X21-2465630 Field_7: CAB U.A/C,MW,3G,1ATT |
|||
| ? | 702-16-53170 | • PISTON | 4 | Field_1: Field_2: Y221319 Field_3: Field_4: Field_5: 8 Field_6: X21-2465630 Field_7: CAB U.A/C,MW,3G,1ATT |
|||
| ? | 702-16-71150 | • SEAL | 4 | Field_1: Field_2: Y221319 Field_3: Field_4: Field_5: 9 Field_6: X21-2465630 Field_7: CAB U.A/C,MW,3G,1ATT |
|||
| ? | 702-16-71160 | • SEAT | 4 | Field_1: Field_2: Y221319 Field_3: Field_4: Field_5: 10 Field_6: X21-2465630 Field_7: CAB U.A/C,MW,3G,1ATT |
|||
| ? | • CASE | 1 | Field_1: Field_2: Y221319 Field_3: Field_4: C1 Field_5: 11 Field_6: X21-2465630 Field_7: CAB U.A/C,MW,3G,1ATT |
||||
| ? | • LEVER | 2 | Field_1: Field_2: Y221319 Field_3: Field_4: C1 Field_5: 12 Field_6: X21-2465630 Field_7: CAB U.A/C,MW,3G,1ATT |
||||
| ? | • SHAFT | 2 | Field_1: Field_2: Y221319 Field_3: Field_4: C1 Field_5: 13 Field_6: X21-2465630 Field_7: CAB U.A/C,MW,3G,1ATT |
||||
| ? | 702-16-73640 | • PLATE | 1 | Field_1: Field_2: Y221319 Field_3: Field_4: Field_5: 14 Field_6: X21-2465630 Field_7: CAB U.A/C,MW,3G,1ATT |
|||
| ? | 01010-80855 | • BOLT | 2 | Field_1: Field_2: Y221319 Field_3: Field_4: Field_5: 15 Field_6: X21-2465630 Field_7: CAB U.A/C,MW,3G,1ATT |
|||
| ? | 01643-30823 | • WASHER | 2 | Field_1: Field_2: Y221319 Field_3: Field_4: Field_5: 16 Field_6: X21-2465630 Field_7: CAB U.A/C,MW,3G,1ATT |
|||
| ? | 01010-80820 | • BOLT | 4 | Field_1: Field_2: Y221319 Field_3: Field_4: Field_5: 17 Field_6: X21-2465630 Field_7: CAB U.A/C,MW,3G,1ATT |
|||
| ? | • PIN,SPRING | 2 | Field_1: Field_2: Y221319 Field_3: Field_4: C1 Field_5: 18 Field_6: X21-2465630 Field_7: CAB U.A/C,MW,3G,1ATT |
||||
| ? | • BUSHING | 4 | Field_1: Field_2: Y221319 Field_3: Field_4: C1 Field_5: 19 Field_6: X21-2465630 Field_7: CAB U.A/C,MW,3G,1ATT |
||||
| ? | 702-16-54331 | • WASHER{T=1.60MM} | 4 | Field_1: Field_2: Y221319 Field_3: Field_4: Field_5: 20 Field_6: X21-2465630 Field_7: CAB U.A/C,MW,3G,1ATT |
|||
| ? | 702-16-54341 | • WASHER{T=1.30MM} | 4 | Field_1: Field_2: Y221319 Field_3: Field_4: Field_5: 21 Field_6: X21-2465630 Field_7: CAB U.A/C,MW,3G,1ATT |
|||
| ? | 702-16-54351 | • WASHER{T=1.00MM} | 4 | Field_1: Field_2: Y221319 Field_3: Field_4: Field_5: 22 Field_6: X21-2465630 Field_7: CAB U.A/C,MW,3G,1ATT |
|||
| ? | 702-16-56380 | • WASHER{T=1.90MM} | 4 | Field_1: Field_2: Y221319 Field_3: Field_4: Field_5: 23 Field_6: X21-2465630 Field_7: CAB U.A/C,MW,3G,1ATT |
|||
| ? | 702-16-56390 | • WASHER{T=2.20MM} | 4 | Field_1: Field_2: Y221319 Field_3: Field_4: Field_5: 24 Field_6: X21-2465630 Field_7: CAB U.A/C,MW,3G,1ATT |
|||
| ? | • O-RING | 2 | Field_1: Field_2: Y221319 Field_3: Field_4: C1 Field_5: 25 Field_6: X21-2465630 Field_7: CAB U.A/C,MW,3G,1ATT |
||||
| ? | 702-16-73610 | • DAMPER ASSEMBLY | 2 | Field_1: Field_2: Y221319 Field_3: Field_4: Field_5: 26 Field_6: X21-2465630 Field_7: CAB U.A/C,MW,3G,1ATT |
|||
| ? | 01023-10306 | • SCREW | 4 | Field_1: Field_2: Y221319 Field_3: Field_4: Field_5: 27 Field_6: X21-2465630 Field_7: CAB U.A/C,MW,3G,1ATT |
|||
| ? | • PIN | 2 | Field_1: Field_2: Y221319 Field_3: Field_4: C1 Field_5: 28 Field_6: X21-2465630 Field_7: CAB U.A/C,MW,3G,1ATT |
||||
| ? | 04022-04016 | • PIN,DOWEL | 2 | Field_1: Field_2: Y221319 Field_3: Field_4: Field_5: 29 Field_6: X21-2465630 Field_7: CAB U.A/C,MW,3G,1ATT |
|||
| ? | • PLUG | 2 | Field_1: Field_2: Y221319 Field_3: Field_4: C1 Field_5: 30 Field_6: X21-2465630 Field_7: CAB U.A/C,MW,3G,1ATT |
||||
| ? | • PLUG | 2 | Field_1: Field_2: Y221319 Field_3: Field_4: C1 Field_5: 31 Field_6: X21-2465630 Field_7: CAB U.A/C,MW,3G,1ATT |
