Содержание Excavators Komatsu PC220-8M0 S/N Y221001-UP(ZEPB401)
CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 1-ADDITIONAL ACTUATOR PIPING,ACCUMULATOR,WEBASTO HEATER) (KOMTRAX ANTENNA) (2(|ZK00228 : |ZK00228)
Номер на схеме Каталожный номер Название Количество Детали
? 20Y-53-00972 CAB ASSEMBLY 1
Field_1:
Field_2: Y221045
Field_3:
Field_4:
Field_5: 1
Field_6: X21-1995260
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 1-ADDITIONAL
? 20Y-53-12960 • COVER 2
Field_1:
Field_2: Y221045
Field_3:
Field_4:
Field_5: 2
Field_6: X21-1995260
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 1-ADDITIONAL
? 22B-54-17282 • CAP 3
Field_1:
Field_2: Y221045
Field_3:
Field_4:
Field_5: 3
Field_6: X21-1995260
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 1-ADDITIONAL
? 09415-02512 • CAP 1
Field_1:
Field_2: Y221045
Field_3:
Field_4:
Field_5: 4
Field_6: X21-1995260
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 1-ADDITIONAL
? 20Y-53-11390 • CAP 6
Field_1:
Field_2: Y221045
Field_3:
Field_4:
Field_5: 5
Field_6: X21-1995260
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 1-ADDITIONAL
? 20Y-53-11390 • CAP 2
Field_1:
Field_2: Y221045
Field_3:
Field_4:
Field_5: 6
Field_6: X21-1995260
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 1-ADDITIONAL
? 20Y-53-11380 • CAP 4
Field_1:
Field_2: Y221045
Field_3:
Field_4:
Field_5: 7
Field_6: X21-1995260
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 1-ADDITIONAL
? 01245-01016 • SCREW 2
Field_1:
Field_2: Y221045
Field_3:
Field_4:
Field_5: 8
Field_6: X21-1995260
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 1-ADDITIONAL
? 01643-71032 • WASHER 2
Field_1:
Field_2: Y221045
Field_3:
Field_4:
Field_5: 9
Field_6: X21-1995260
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 1-ADDITIONAL
? 01245-00616 • SCREW 4
Field_1:
Field_2: Y221045
Field_3:
Field_4:
Field_5: 10
Field_6: X21-1995260
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 1-ADDITIONAL
? 01643-70623 • WASHER 4
Field_1:
Field_2: Y221045
Field_3:
Field_4:
Field_5: 11
Field_6: X21-1995260
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 1-ADDITIONAL
? 20Y-53-12260 • NUT 6
Field_1:
Field_2: Y221045
Field_3:
Field_4:
Field_5: 12
Field_6: X21-1995260
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 1-ADDITIONAL
? 20Y-54-35451 • NUT 2
Field_1:
Field_2: Y221045
Field_3:
Field_4:
Field_5: 13
Field_6: X21-1995260
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 1-ADDITIONAL
? 20Y-53-12320 • NUT 2
Field_1:
Field_2: Y221045
Field_3:
Field_4:
Field_5: 14
Field_6: X21-1995260
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 1-ADDITIONAL
? 09415-01008 • CAP 1
Field_1:
Field_2: Y221045
Field_3:
Field_4:
Field_5: 15
Field_6: X21-1995260
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 1-ADDITIONAL
? 01245-01016 • SCREW 1
Field_1:
Field_2: Y221045
Field_3:
Field_4:
Field_5: 16
Field_6: X21-1995260
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 1-ADDITIONAL
? 01643-71032 • WASHER 1
Field_1:
Field_2: Y221045
Field_3:
Field_4:
Field_5: 17
Field_6: X21-1995260
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 1-ADDITIONAL
? 20Y-53-12580 • SEAL 1
Field_1:
Field_2: Y221045
Field_3:
Field_4:
Field_5: 18
Field_6: X21-1995260
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 1-ADDITIONAL
? 2A5-53-13381 • TRIM 1
Field_1:
Field_2: Y221045
Field_3:
Field_4:
Field_5: 19
Field_6: X21-1995260
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 1-ADDITIONAL
? 20Y-53-12740 • TRIM 1
Field_1:
Field_2: Y221045
Field_3: 100524
Field_4: A2
Field_5: 20
Field_6: X21-1995260
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 1-ADDITIONAL
? 20Y-53-12270 • NUT 2
Field_1:
Field_2: Y221045
Field_3:
Field_4:
Field_5: 21
Field_6: X21-1995260
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 1-ADDITIONAL
? 01245-00816 • SCREW 2
Field_1:
Field_2: Y221045
Field_3:
Field_4:
Field_5: 22
Field_6: X21-1995260
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 1-ADDITIONAL
? 01643-70823 • WASHER 2
Field_1:
Field_2: Y221045
Field_3:
Field_4:
Field_5: 23
Field_6: X21-1995260
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 1-ADDITIONAL
? 2A5-53-11361 • SEAL 2
Field_1:
Field_2: Y221045
Field_3:
Field_4:
Field_5: 24
Field_6: X21-1995260
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 1-ADDITIONAL
? 8A13-10-1320 • ANTENNA 1
Field_1:
Field_2: Y221045
Field_3:
Field_4:
Field_5: 25
Field_6: X21-1995260
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 1-ADDITIONAL
? 20Y-53-12951 • COVER 1
Field_1:
Field_2: Y221045
Field_3:
Field_4:
Field_5: 26
Field_6: X21-1995260
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 1-ADDITIONAL
? 2A5-53-12130 • GROMMET 1
Field_1:
Field_2: Y221045
Field_3:
Field_4:
Field_5: 27
Field_6: X21-1995260
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 1-ADDITIONAL
? 8A13-10-3110 • ANTENNA 1
Field_1:
Field_2: Y221045
Field_3:
Field_4:
Field_5: 28
Field_6: X21-1995260
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 1-ADDITIONAL
? 20Y-53-14311 • PLATE 1
Field_1:
Field_2: Y221045
Field_3:
Field_4:
Field_5: 29
Field_6: X21-1995260
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 1-ADDITIONAL
? 08037-01610 • GROMMET 1
Field_1:
Field_2: Y221045
Field_3:
Field_4:
Field_5: 30
Field_6: X21-1995260
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 1-ADDITIONAL
? 01435-00616 • BOLT 1
Field_1:
Field_2: Y221045
Field_3:
Field_4:
Field_5: 31
Field_6: X21-1995260
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 1-ADDITIONAL
? 08034-20414 • BAND{BLACK} 2
Field_1:
Field_2: Y221045
Field_3:
Field_4:
Field_5: 32
Field_6: X21-1995260
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 1-ADDITIONAL
