Содержание Excavators Komatsu PC220-8M0 S/N Y221001-UP(ZEPB401)
CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 2-ADDITIONAL ACTUATOR PIPING,ACCUMULATOR,WEBASTO HEATER) (FRONT WINDOW)(|ZK00153 : |ZK00153)
Номер на схеме Каталожный номер Название Количество Детали
? 20Y-53-00972 CAB ASSEMBLY 1
Field_1:
Field_2: Y221001
Field_3:
Field_4:
Field_5: 1
Field_6: X21-1995270
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 2-ADDITIONAL
? 20Y-53-00971 CAB ASSEMBLY 1
Field_1:
Field_2: Y221001
Field_3: 100471
Field_4: A2
Field_5: 2
Field_6: X21-1995270
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 2-ADDITIONAL
? 20Y-53-00380 • WINDOW ASSEMBLY 1
Field_1:
Field_2: Y221001
Field_3:
Field_4:
Field_5: 3
Field_6: X21-1995270
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 2-ADDITIONAL
? 2A5-53-12491 • • FRAME 1
Field_1:
Field_2: Y221001
Field_3:
Field_4:
Field_5: 4
Field_6: X21-1995270
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 2-ADDITIONAL
? 20Y-53-11520 • • GLASS 1
Field_1:
Field_2: Y221001
Field_3:
Field_4:
Field_5: 5
Field_6: X21-1995270
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 2-ADDITIONAL
? 20Y-54-51531 • • SEAL 1
Field_1:
Field_2: Y221001
Field_3:
Field_4:
Field_5: 6
Field_6: X21-1995270
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 2-ADDITIONAL
? 20Y-53-11551 • • SEAL 1
Field_1:
Field_2: Y221001
Field_3:
Field_4:
Field_5: 7
Field_6: X21-1995270
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 2-ADDITIONAL
? 22B-54-15411 • • LOCK ASSEMBLY 1
Field_1:
Field_2: Y221001
Field_3:
Field_4:
Field_5: 8
Field_6: X21-1995270
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 2-ADDITIONAL
? 22B-54-15440 • • CASE 1
Field_1:
Field_2: Y221001
Field_3:
Field_4:
Field_5: 9
Field_6: X21-1995270
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 2-ADDITIONAL
? 22B-54-15470 • • KNOB 1
Field_1:
Field_2: Y221001
Field_3:
Field_4:
Field_5: 10
Field_6: X21-1995270
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 2-ADDITIONAL
? 22B-54-15421 • • LOCK ASSEMBLY 1
Field_1:
Field_2: Y221001
Field_3:
Field_4:
Field_5: 11
Field_6: X21-1995270
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 2-ADDITIONAL
? 22B-54-15450 • • CASE 1
Field_1:
Field_2: Y221001
Field_3:
Field_4:
Field_5: 12
Field_6: X21-1995270
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 2-ADDITIONAL
? 22B-54-15480 • • KNOB 1
Field_1:
Field_2: Y221001
Field_3:
Field_4:
Field_5: 13
Field_6: X21-1995270
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 2-ADDITIONAL
? 01435-40812 • • BOLT 4
Field_1:
Field_2: Y221001
Field_3:
Field_4:
Field_5: 14
Field_6: X21-1995270
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 2-ADDITIONAL
? 20Y-54-52621 • • ROLLER 2
Field_1:
Field_2: Y221001
Field_3:
Field_4:
Field_5: 15
Field_6: X21-1995270
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 2-ADDITIONAL
? 20Y-54-52681 • • ROLLER 2
Field_1:
Field_2: Y221001
Field_3:
Field_4:
Field_5: 16
Field_6: X21-1995270
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 2-ADDITIONAL
? 20Y-53-12330 • • PIN 1
Field_1:
Field_2: Y221001
Field_3:
Field_4:
Field_5: 17
Field_6: X21-1995270
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 2-ADDITIONAL
? 20Y-54-14590 • • HANDLE 2
Field_1:
Field_2: Y221001
Field_3:
Field_4:
Field_5: 18
Field_6: X21-1995270
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 2-ADDITIONAL
? 01245-00616 • • SCREW 4
Field_1:
Field_2: Y221001
Field_3:
Field_4:
Field_5: 19
Field_6: X21-1995270
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 2-ADDITIONAL
? 01643-70623 • • WASHER 4
Field_1:
Field_2: Y221001
Field_3:
Field_4:
Field_5: 20
Field_6: X21-1995270
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 2-ADDITIONAL
? 20Y-53-12830 • • BRACKET 1
Field_1:
Field_2: Y221001
Field_3:
Field_4:
Field_5: 21
Field_6: X21-1995270
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 2-ADDITIONAL
? 01245-00816 • • SCREW 2
Field_1:
Field_2: Y221001
Field_3:
Field_4:
Field_5: 22
Field_6: X21-1995270
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 2-ADDITIONAL
? 01643-70823 • • WASHER 2
Field_1:
Field_2: Y221001
Field_3:
Field_4:
Field_5: 23
Field_6: X21-1995270
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 2-ADDITIONAL
? 20Y-54-51670 • STOPPER 1
Field_1:
Field_2: Y221001
Field_3:
Field_4:
Field_5: 24
Field_6: X21-1995270
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 2-ADDITIONAL
? 20Y-54-51680 • STOPPER 1
Field_1:
Field_2: Y221001
Field_3:
Field_4:
Field_5: 25
Field_6: X21-1995270
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 2-ADDITIONAL
? 01252-80616 • BOLT 4
Field_1:
Field_2: Y221001
Field_3:
Field_4:
Field_5: 26
Field_6: X21-1995270
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 2-ADDITIONAL
? 01643-70623 • WASHER 4
Field_1:
Field_2: Y221001
Field_3:
Field_4:
Field_5: 27
Field_6: X21-1995270
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 2-ADDITIONAL
? 20Y-53-11561 • BLOCK ASSEMBLY 1
Field_1:
Field_2: Y221001
Field_3:
Field_4:
Field_5: 28
Field_6: X21-1995270
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 2-ADDITIONAL
? 01245-00816 • SCREW 2
Field_1:
Field_2: Y221001
Field_3:
Field_4:
Field_5: 29
Field_6: X21-1995270
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 2-ADDITIONAL
? 01643-70823 • WASHER 2
Field_1:
Field_2: Y221001
Field_3:
Field_4:
Field_5: 30
Field_6: X21-1995270
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 2-ADDITIONAL
? 20Y-53-11661 • BRACKET 1
Field_1:
Field_2: Y221001
Field_3:
Field_4:
Field_5: 31
Field_6: X21-1995270
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 2-ADDITIONAL
? 01245-00816 • SCREW 2
Field_1:
Field_2: Y221001
Field_3:
Field_4:
Field_5: 32
Field_6: X21-1995270
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 2-ADDITIONAL
? 01643-70823 • WASHER 2
Field_1:
Field_2: Y221001
Field_3:
Field_4:
Field_5: 33
Field_6: X21-1995270
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 2-ADDITIONAL
? 21J-06-12440 • SWITCH 1
Field_1:
Field_2: Y221001
Field_3:
Field_4:
Field_5: 34
Field_6: X21-1995270
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 2-ADDITIONAL
? 01583-11811 • NUT 1
Field_1:
Field_2: Y221001
Field_3:
Field_4:
Field_5: 35
Field_6: X21-1995270
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 2-ADDITIONAL
? 20Y-53-11581 • BRACKET 1
Field_1:
Field_2: Y221001
Field_3:
Field_4:
Field_5: 36
Field_6: X21-1995270
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 2-ADDITIONAL
? 2A5-53-12850 • BRACKET 1
Field_1:
Field_2: Y221001
Field_3:
Field_4:
Field_5: 37
Field_6: X21-1995270
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 2-ADDITIONAL
? 01435-00612 • BOLT 4
Field_1:
Field_2: Y221001
Field_3:
Field_4:
Field_5: 38
Field_6: X21-1995270
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 2-ADDITIONAL
? 08059-00515 • CLIP 1
Field_1:
Field_2: Y221001
Field_3:
Field_4:
Field_5: 39
Field_6: X21-1995270
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 2-ADDITIONAL
? 20Y-54-11611 • STOPPER 2
Field_1:
Field_2: Y221001
Field_3:
Field_4:
Field_5: 40
Field_6: X21-1995270
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 2-ADDITIONAL
? 01580-11008 • NUT 2
Field_1:
Field_2: Y221001
Field_3:
Field_4:
Field_5: 41
Field_6: X21-1995270
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 2-ADDITIONAL
? 20Y-54-51621 • STRIKER 2
Field_1:
Field_2: Y221001
Field_3:
Field_4:
Field_5: 42
Field_6: X21-1995270
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 2-ADDITIONAL
? 01584-31008 • NUT 2
Field_1:
Field_2: Y221001
Field_3:
Field_4:
Field_5: 43
Field_6: X21-1995270
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 2-ADDITIONAL
? 01643-71032 • WASHER 2
Field_1:
Field_2: Y221001
Field_3:
Field_4:
Field_5: 44
Field_6: X21-1995270
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 2-ADDITIONAL
? 20Y-53-11540 • TRIM 1
Field_1:
Field_2: Y221001
Field_3:
Field_4:
Field_5: 45
Field_6: X21-1995270
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 2-ADDITIONAL
? 20Y-54-51420 • SEAL 1
Field_1:
Field_2: Y221001
Field_3:
Field_4:
Field_5: 46
Field_6: X21-1995270
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 2-ADDITIONAL
? 20Y-53-12531 • COVER 1
Field_1:
Field_2: Y221001
Field_3:
Field_4:
Field_5: 47
Field_6: X21-1995270
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 2-ADDITIONAL
? 20Y-53-12310 • COLLAR 3
Field_1:
Field_2: Y221001
Field_3:
Field_4:
Field_5: 48
Field_6: X21-1995270
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 2-ADDITIONAL
? 01245-00616 • SCREW 3
Field_1:
Field_2: Y221001
Field_3:
Field_4:
Field_5: 49
Field_6: X21-1995270
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 2-ADDITIONAL
? 01643-70623 • WASHER 3
Field_1:
Field_2: Y221001
Field_3:
Field_4:
Field_5: 50
Field_6: X21-1995270
Field_7: CAB (VANDALISM PROTECTION,POWER SUPPLY,12VOLT,WITH 2-ADDITIONAL
