| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 207-54-71840 | SUPPORT | 1 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 1 Field_6: X21-0898320 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 20Y-54-61630 | CLAMP | 1 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 2 Field_6: X21-0898320 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 01252-71030 | BOLT | 2 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 3 Field_6: X21-0898320 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 421-54-25610 | MIRROR | 1 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 4 Field_6: X21-0898320 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 421-54-25620 | • BUSHING | 2 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 5 Field_6: X21-0898320 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 421-54-25630 | • HOLDER | 1 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 6 Field_6: X21-0898320 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 421-54-25640 | • LENS | 1 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 7 Field_6: X21-0898320 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 421-54-25650 | • FRAME | 1 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 8 Field_6: X21-0898320 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 421-54-25660 | • SCREW{(SHIPPING ONLY)} | 4 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 9 Field_6: X21-0898320 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 04025-00632 | PIN | 1 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 10 Field_6: X21-0898320 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 01252-70545 | BOLT | 4 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 11 Field_6: X21-0898320 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 209-98-77220 | PLATE | 1 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 12 Field_6: X21-0898320 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 207-54-71864 | PLATE | 1 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 13 Field_6: X21-0898320 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 207-54-71863 | PLATE | 1 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 14 Field_6: X21-0898320 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 207-54-66120 | GRIP | 1 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 15 Field_6: X21-0898320 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 01010-81225 | BOLT | 2 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 16 Field_6: X21-0898320 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 01643-31232 | WASHER | 2 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 17 Field_6: X21-0898320 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 07049-01215 | PLUG | 2 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 18 Field_6: X21-0898320 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
