Содержание Excavators Komatsu PC400-7(-50) S/N Y400001-UP(ZEPB000901)
CYLINDER BLOCK(#310001-)(|AAA0076 : |AAA0076)
Номер на схеме Каталожный номер Название Количество Детали
? 6154-21-1100 CYLINDER BLOCK ASS'Y 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 1
Field_6: X16-0370390
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? • BLOCK{CYLINDER} 1
Field_1:
Field_2: Y400001
Field_3:
Field_4: C1
Field_5: 2
Field_6: X16-0370390
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 6150-21-1490 • BUSHING{CAMSHAFT} 7
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 3
Field_6: X16-0370390
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 6150-29-1210 • CAP{MAIN METAL, NO.1,2,3,4,5,6} 6
Field_1:
Field_2: Y400001
Field_3:
Field_4: C3
Field_5: 4
Field_6: X16-0370390
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 6150-29-1250 • CAP{MAIN METAL, NO.7} 1
Field_1:
Field_2: Y400001
Field_3:
Field_4: C3
Field_5: 5
Field_6: X16-0370390
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 04020-00514 • PIN{DOWEL} 2
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 6
Field_6: X16-0370390
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 6150-21-1710 • BOLT 14
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 7
Field_6: X16-0370390
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 01643-31645 • WASHER 14
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 8
Field_6: X16-0370390
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 07043-50108 • PLUG 6
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 9
Field_6: X16-0370390
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 07043-50211 • PLUG 3
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 10
Field_6: X16-0370390
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 07043-70617 • PLUG 3
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 11
Field_6: X16-0370390
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 07043-50617 • PLUG 3
Field_1:
Field_2: Y400001
Field_3: 319374
Field_4:
Field_5: 12
Field_6: X16-0370390
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 07040-12414 • PLUG 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 13
Field_6: X16-0370390
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 07040-13016 • PLUG 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 14
Field_6: X16-0370390
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 07002-23034 • O-RING\((K2)\) 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 15
Field_6: X16-0370390
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 07002-22434 • O-RING\((K2)\) 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 16
Field_6: X16-0370390
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 07046-43016 • PLUG 3
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 17
Field_6: X16-0370390
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 07046-44016 • PLUG 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 18
Field_6: X16-0370390
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 6154-21-1981 • PLUG 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 19
Field_6: X16-0370390
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 07000-72022 • O-RING\((K2)\) 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 20
Field_6: X16-0370390
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 07046-21210 • PLUG 4
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 21
Field_6: X16-0370390
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 07046-43516 • PLUG 4
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 22
Field_6: X16-0370390
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 04020-00820 • PIN{DOWEL} 12
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 23
Field_6: X16-0370390
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 6150-21-1170 • TUBE 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 24
Field_6: X16-0370390
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 6150-41-2430 • PIN 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 25
Field_6: X16-0370390
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 6150-41-2440 • PIN 2
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 26
Field_6: X16-0370390
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 04025-00408 • PIN{ROLL} 6
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 27
Field_6: X16-0370390
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 6150-21-4770 • PIN{DOWEL} 2
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 28
Field_6: X16-0370390
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 6150-41-2430 • PIN 12
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 29
Field_6: X16-0370390
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 04020-01024 PIN{DOWEL} 2
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 30
Field_6: X16-0370390
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 04025-00512 PIN{SPRING} 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 31
Field_6: X16-0370390
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 6154-21-2220 LINER{CYLINDER} 6
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 32
Field_6: X16-0370390
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 6150-21-2230 O-RING{LOWER}\((K2)\) 6
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 33
Field_6: X16-0370390
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 6251-21-2240 O-RING{CENTER}\((K2)\) 6
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 34
Field_6: X16-0370390
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 6150-21-2240 O-RING{CENTER}\((K2)\) 6
Field_1:
Field_2: Y400001
Field_3: 319109
Field_4:
Field_5: 35
Field_6: X16-0370390
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 6150-21-2250 SEAL{CREVICE}\((K2)\) 6
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 36
Field_6: X16-0370390
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 6154-21-1810 NOZZLE{PISTON COOLING} 6
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 37
Field_6: X16-0370390
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 01435-00816 BOLT 6
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 38
Field_6: X16-0370390
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:

Excavators Komatsu / PC400-7(-50) S/N Y400001-UP(ZEPB000901) / CYLINDER BLOCK(#310001-)(|AAA0076 : |AAA0076)
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
