| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 208-62-72960 | TUBE | 1 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 1 Field_6: X21-1047250 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 07000-13035 | O-RING | 1 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 2 Field_6: X21-1047250 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 07000-13032 | O-RING | 1 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 3 Field_6: X21-1047250 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 07372-21040 | BOLT | 4 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 4 Field_6: X21-1047250 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 01643-51032 | WASHER | 4 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 5 Field_6: X21-1047250 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 208-62-72970 | TUBE | 1 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 6 Field_6: X21-1047250 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 07000-13035 | O-RING | 1 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 7 Field_6: X21-1047250 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 07000-13032 | O-RING | 1 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 8 Field_6: X21-1047250 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 07372-21040 | BOLT | 4 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 9 Field_6: X21-1047250 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 01643-51032 | WASHER | 4 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 10 Field_6: X21-1047250 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 208-62-71170 | HOSE, 1210MM | 1 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 11 Field_6: X21-1047250 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 07000-13032 | O-RING | 2 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 12 Field_6: X21-1047250 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 208-62-72980 | HOSE, 1150MM | 1 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 13 Field_6: X21-1047250 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 07000-13032 | O-RING | 2 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 14 Field_6: X21-1047250 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 07371-31049 | FLANGE | 8 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 15 Field_6: X21-1047250 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 07372-21035 | BOLT | 16 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 16 Field_6: X21-1047250 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 01643-51032 | WASHER | 16 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 17 Field_6: X21-1047250 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 07379-01044 | FLANGE | 2 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 18 Field_6: X21-1047250 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
