| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6156-11-5840 | BRACKET | 1 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 1 Field_6: X16-0373100 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 01010-E1040 | BOLT | 4 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 2 Field_6: X16-0373100 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 01010-E1025 | BOLT | 4 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 3 Field_6: X16-0373100 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 01643-31032 | WASHER | 4 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 4 Field_6: X16-0373100 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 6156-11-5850 | PLATE | 1 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 5 Field_6: X16-0373100 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 01010-E1025 | BOLT | 4 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 6 Field_6: X16-0373100 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 01643-31032 | WASHER | 4 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 7 Field_6: X16-0373100 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 6156-11-5830 | BRACKET | 1 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 8 Field_6: X16-0373100 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 01435-01025 | BOLT | 4 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 9 Field_6: X16-0373100 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 01010-E1030 | BOLT | 6 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 10 Field_6: X16-0373100 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 01643-31032 | WASHER | 6 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 11 Field_6: X16-0373100 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 6151-11-8441 | PLATE | 1 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 12 Field_6: X16-0373100 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 01010-E1016 | BOLT | 5 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 13 Field_6: X16-0373100 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
