Содержание Excavators Komatsu PC400-7(-50) S/N Y400001-UP(ZEPB000901)
HYDRAULIC TANK (FOR ANTI-DROP VALVE)(|ZH00002 : |ZH00002)
Номер на схеме Каталожный номер Название Количество Детали
? 208-60-71113 TANK 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 1
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 203-60-31100 ELBOW ASS'Y 2
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 2
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 203-60-31160 TUBE 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 3
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 07044-12412 PLUG 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 4
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 07002-12434 O-RING 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 5
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 207-62-72171 ELBOW 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 6
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 07002-12434 O-RING 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 7
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 02896-11018 O-RING 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 8
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 02782-10522 ELBOW 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 9
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 07002-12434 O-RING 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 10
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 02896-11015 O-RING 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 11
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 02782-10315 ELBOW 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 12
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 07002-12034 O-RING 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 13
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 02896-11009 O-RING 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 14
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 207-62-72110 UNION 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 15
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 07002-13334 O-RING 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 16
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 207-62-64740 O-RING 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 17
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 02782-10315 ELBOW 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 18
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 07002-12034 O-RING 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 19
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 02896-11009 O-RING 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 20
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 02783-10210 ELBOW 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 21
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 07002-11423 O-RING 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 22
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 02896-11008 O-RING 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 23
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 208-60-71123 ELEMENT 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 24
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 208-60-71122 ELEMENT 1
Field_1:
Field_2: Y400001
Field_3:
Field_4: A2
Field_5: 25
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 208-60-71121 ELEMENT 1
Field_1:
Field_2: Y400001
Field_3:
Field_4: A2
Field_5: 26
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 208-60-71120 ELEMENT 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 27
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 07069-25400 STRAINER 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 28
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 208-60-71160 VALVE ASS'Y 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 29
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 07069-34075 SPRING 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 30
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 208-60-71130 PLATE 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 31
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 07000-15210 O-RING 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 32
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 01010-81225 BOLT 4
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 33
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 01643-31232 WASHER 4
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 34
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 208-60-71140 STRAINER ASS'Y 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 35
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 208-60-71150 • ROD ASS'Y 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 36
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 12R-60-11230 • • SPRING 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 37
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 20Y-60-21320 • • HOLDER 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 38
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 22B-60-11160 • STRAINER 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 39
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 208-60-61190 COVER 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 40
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 07000-15180 O-RING 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 41
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 01010-81225 BOLT 4
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 42
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 01643-31232 WASHER 4
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 43
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? (198-60-55510) BREATHER 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 44
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 17A-60-11310 CAP ASS'Y 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 45
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 20Y-60-21470 • ELEMENT 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 46
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 208-60-71181 FILLER NECK 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 47
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 208-60-71180 FILLER NECK 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 48
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 20Y-60-21460 NECK 1
Field_1:
Field_2: Y400001
Field_3:
Field_4: A2
Field_5: 49
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 20Y-60-21340 GASKET 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 50
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 01252-70516 BOLT 6
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 51
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 01601-20513 WASHER 6
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 52
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 07285-00200 CLIP 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 53
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 07285-00155 CLIP 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 54
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 07261-21431 HOSE 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 55
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 07270-61431 TUBE 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 56
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 07270-61420 TUBE 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 57
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 07056-10045 STRAINER 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 58
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 04065-04718 RING 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 59
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 208-60-71250 SHEET 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 60
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 01010-81635 BOLT 6
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 61
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 01643-31645 WASHER 6
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 62
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 195-03-11570 SHIM, 1.0MM 2
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 63
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 08034-20519 BAND 4
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 64
Field_6: X21-1024000
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:

Excavators Komatsu / PC400-7(-50) S/N Y400001-UP(ZEPB000901) / HYDRAULIC TANK (FOR ANTI-DROP VALVE)(|ZH00002 : |ZH00002)
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
