Содержание Excavators Komatsu PC400-7(-50) S/N Y400001-UP(ZEPB000901)
AIR CLEANER (WITH PRE-CLEANER)(|ZB00007 : |ZB00007)
Номер на схеме Каталожный номер Название Количество Детали
? (6156-81-7202) AIR CLEANER ASS'Y 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 1
Field_6: X21-1014320
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? (6156-81-7201) AIR CLEANER ASS'Y 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 2
Field_6: X21-1014320
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? (6156-81-7200) AIR CLEANER ASS'Y 1
Field_1:
Field_2: Y400001
Field_3:
Field_4: B1
Field_5: 3
Field_6: X21-1014320
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 6151-11-9970 BAND ASS'Y 2
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 4
Field_6: X21-1014320
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 6643-11-4641 BOLT 2
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 5
Field_6: X21-1014320
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 208-01-72121 BRACKET 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 6
Field_6: X21-1014320
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 01010-81225 BOLT 4
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 7
Field_6: X21-1014320
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 01643-31232 WASHER 4
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 8
Field_6: X21-1014320
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 11Y-01-11920 JOINT 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 9
Field_6: X21-1014320
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 208-01-72310 SEAL 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 10
Field_6: X21-1014320
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 208-01-72111 HOSE 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 11
Field_6: X21-1014320
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 208-01-72180 CLAMP 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 12
Field_6: X21-1014320
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 07299-00130 CLAMP 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 13
Field_6: X21-1014320
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 208-01-72151 TUBE 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 14
Field_6: X21-1014320
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 07283-31185 CLIP 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 15
Field_6: X21-1014320
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 01597-01211 NUT 2
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 16
Field_6: X21-1014320
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 01643-31232 WASHER 2
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 17
Field_6: X21-1014320
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 208-01-72161 HOSE 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 18
Field_6: X21-1014320
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 07299-00130 CLAMP 2
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 19
Field_6: X21-1014320
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 208-01-72141 BRACKET 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 20
Field_6: X21-1014320
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 01010-81025 BOLT 2
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 21
Field_6: X21-1014320
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 01643-31032 WASHER 2
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 22
Field_6: X21-1014320
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 20Y-06-42910 SENSOR 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 23
Field_6: X21-1014320
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 7861-93-1422 SENSOR 1
Field_1:
Field_2: Y400001
Field_3:
Field_4: A2
Field_5: 24
Field_6: X21-1014320
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 7861-93-1421 SENSOR 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 25
Field_6: X21-1014320
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 7861-93-1420 SENSOR 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 26
Field_6: X21-1014320
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
