| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6152-12-3110 | HOLDER ASS'Y | 6 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 1 Field_6: X16-0372930 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | DK150525-1700 | • PIN | 2 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 2 Field_6: X16-0372930 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | DK150550-5900 | • ROD{PUSH} | 1 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 3 Field_6: X16-0372930 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | DK150562-6200 | • SPRING{NOZZLE} | 1 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 4 Field_6: X16-0372930 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | DK150590-0600 | • SHIM, 0.40MM | A/R | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 5 Field_6: X16-0372930 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | DK150590-0700 | • SHIM, 0.50MM | A/R | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 6 Field_6: X16-0372930 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | DK150590-0800 | • SHIM, 0.52MM | A/R | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 7 Field_6: X16-0372930 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | DK150590-0900 | • SHIM, 0.54MM | A/R | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 8 Field_6: X16-0372930 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | DK150590-1000 | • SHIM, 0.56MM | A/R | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 9 Field_6: X16-0372930 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | DK150590-1100 | • SHIM, 0.58MM | A/R | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 10 Field_6: X16-0372930 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | DK150590-1200 | • SHIM, 0.60MM | A/R | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 11 Field_6: X16-0372930 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | DK150590-1300 | • SHIM, 0.70MM | A/R | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 12 Field_6: X16-0372930 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | DK150524-4300 | • SPACER | 1 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 13 Field_6: X16-0372930 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | DK150650-9400 | • NUT{RETAINING} | 1 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 14 Field_6: X16-0372930 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | DK029300-5070 | • GASKET | 1 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 15 Field_6: X16-0372930 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | DK150645-8100 | • CONNECTOR | 1 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 16 Field_6: X16-0372930 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 6127-11-3152 | • BOLT{JOINT} | 1 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 17 Field_6: X16-0372930 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 07005-00812 | • SEAL, WASHER | 2 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 18 Field_6: X16-0372930 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
