| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6217-71-7300 | HEAD ASS'Y (1-5/8) | 1 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 1 Field_6: X16-0382780 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 6217-71-7310 | • HEAD (1-5/8) | 1 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 2 Field_6: X16-0382780 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 6110-73-6231 | • PLUG | 1 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 3 Field_6: X16-0382780 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 07005-00812 | • SEAL, WASHER | 1 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 4 Field_6: X16-0382780 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 07043-70108 | • PLUG | 1 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 5 Field_6: X16-0382780 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | CARTRIDGE{(SEE FIG.A4119-A4A3)} | 1 | Field_1: Field_2: Y400001 Field_3: Field_4: C1 Field_5: 6 Field_6: X16-0382780 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
||||
| ? | CARTRIDGE{(SEE FIG.A4119-A4A1)} | 1 | Field_1: Field_2: Y400001 Field_3: 321458 Field_4: C1 Field_5: 7 Field_6: X16-0382780 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
||||
| ? | CARTRIDGE{(SEE FIG.A4119-A4A1)} | 1 | Field_1: Field_2: Y400001 Field_3: 320469 Field_4: C1 Field_5: 8 Field_6: X16-0382780 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
||||
| ? | 01435-01040 | BOLT | 4 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 9 Field_6: X16-0382780 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 6156-71-6410 | BRACKET | 1 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 10 Field_6: X16-0382780 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 01436-01085 | BOLT | 4 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 11 Field_6: X16-0382780 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 6150-71-7130 | COLLAR | 3 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 12 Field_6: X16-0382780 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 6150-71-7130 | COLLAR | 2 | Field_1: Field_2: Y400001 Field_3: 318567 Field_4: Field_5: 13 Field_6: X16-0382780 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 6221-81-6940 | SPACER | 1 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 14 Field_6: X16-0382780 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 01643-31032 | WASHER | 1 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 15 Field_6: X16-0382780 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 6156-71-6420 | TUBE{INLET} | 1 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 16 Field_6: X16-0382780 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 6156-71-6430 | TUBE{OUTLET} | 1 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 17 Field_6: X16-0382780 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 07206-31014 | BOLT{JOINT} | 2 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 18 Field_6: X16-0382780 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 07005-01412 | SEAL, WASHER\((K2)\) | 4 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 19 Field_6: X16-0382780 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 6217-71-6290 | CLAMP | 1 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 20 Field_6: X16-0382780 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 6217-71-6280 | CLAMP | 1 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 21 Field_6: X16-0382780 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 01435-00835 | BOLT | 1 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 22 Field_6: X16-0382780 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
