Содержание Excavators Komatsu PC400-7(-50) S/N Y400001-UP(ZEPB000901)
HEAD COVER(#321812-)(|AAA0013 : |AAA0013)
Номер на схеме Каталожный номер Название Количество Детали
? 6156-11-8500 COVER ASS'Y 5
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 1
Field_6: X16-0376760
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 6156-11-8110 • COVER{HEAD, NO.1,2,3,4,5} 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 2
Field_6: X16-0376760
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 6156-11-8810 • GASKET\((K1)\) 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 3
Field_6: X16-0376760
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 6150-11-8820 RUBBER\((K1)\) 10
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 4
Field_6: X16-0376760
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 6150-81-9370 BOLT 10
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 5
Field_6: X16-0376760
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 01640-21016 WASHER 10
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 6
Field_6: X16-0376760
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 6156-11-8831 SEAL\((K1)\) 5
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 7
Field_6: X16-0376760
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 6156-11-8600 COVER ASS'Y 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 8
Field_6: X16-0376760
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 6156-11-8150 • COVER{HEAD, NO.6} 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 9
Field_6: X16-0376760
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 6156-11-8810 GASKET\((K1)\) 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 10
Field_6: X16-0376760
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 6150-11-8820 RUBBER\((K1)\) 2
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 11
Field_6: X16-0376760
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 6150-81-9370 BOLT 2
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 12
Field_6: X16-0376760
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 01640-21016 WASHER 2
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 13
Field_6: X16-0376760
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:
? 6156-11-8831 SEAL\((K1)\) 1
Field_1:
Field_2: Y400001
Field_3:
Field_4:
Field_5: 14
Field_6: X16-0376760
Field_7:
Field_8:
Field_9:
Field_10:
Field_11:
Field_12:
Field_13:
Field_14:

Excavators Komatsu / PC400-7(-50) S/N Y400001-UP(ZEPB000901) / HEAD COVER(#321812-)(|AAA0013 : |AAA0013)
?
?
?
?
?
?
?
?
?
?
?
?
?
