| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6150-22-6700 | COVER ASS'Y | 2 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 1 Field_6: X16-0381280 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 6150-22-6430 | • COVER | 1 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 2 Field_6: X16-0381280 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 6150-21-6450 | • GASKET\((K2)\) | 1 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 3 Field_6: X16-0381280 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 6150-22-6900 | COVER ASS'Y | 1 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 4 Field_6: X16-0381280 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 6150-22-6600 | • COVER ASS'Y | 1 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 5 Field_6: X16-0381280 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | • • COVER | 1 | Field_1: Field_2: Y400001 Field_3: Field_4: C1 Field_5: 6 Field_6: X16-0381280 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
||||
| ? | • • CONNECTOR | 1 | Field_1: Field_2: Y400001 Field_3: Field_4: C1 Field_5: 7 Field_6: X16-0381280 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
||||
| ? | 6150-21-6450 | • GASKET\((K2)\) | 1 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 8 Field_6: X16-0381280 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 6210-21-6471 | BOLT | 9 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 9 Field_6: X16-0381280 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 6150-21-6391 | PACKING\((K2)\) | 9 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 10 Field_6: X16-0381280 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 6150-21-6710 | BREATHER | 1 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 11 Field_6: X16-0381280 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 6114-21-5190 | O-RING\((K1)\) | 1 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 12 Field_6: X16-0381280 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 07287-01910 | HOSE | 1 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 13 Field_6: X16-0381280 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
|||
| ? | 07285-00220 | CLIP | 1 | Field_1: Field_2: Y400001 Field_3: Field_4: Field_5: 14 Field_6: X16-0381280 Field_7: Field_8: Field_9: Field_10: Field_11: Field_12: Field_13: Field_14: |
