Содержание Bulldozers Komatsu D51EX-24 S/N 10001-UP(0001119C)
Air Conditioner Piping (#10001-)(K020001 : K0710-001001)
Номер на схеме Каталожный номер Название Количество Детали
? 12Y-979-3241 Bracket 1
SN: 10001-
KIT-FLAG: _-
SCC:
SERIALNO: 10001-
? 01010-81025 Bolt 4
SN: 10001-
KIT-FLAG: _-
SCC:
SERIALNO: 10001-
? 01643-31032 Washer 4
SN: 10001-
KIT-FLAG: _-
SCC:
SERIALNO: 10001-
? 12Y-Z79-3121 Compressor 1
SN: 10001-
KIT-FLAG: _-
SCC:
SERIALNO: 10001-
? 01010-80830 Bolt 3
SN: 10001-
KIT-FLAG: _-
SCC:
SERIALNO: 10001-
? 01643-30823 Washer 3
SN: 10001-
KIT-FLAG: _-
SCC:
SERIALNO: 10001-
? 12Y-979-3221 Hose Assembly 1
SN: 10001-
KIT-FLAG: _-
SCC:
SERIALNO: 10001-
? 11Y-979-8530 • Fitting 1
SN: 10001-
KIT-FLAG: _-
SCC:
SERIALNO: 10001-
? 11Y-979-8540 • Cap 1
SN: 10001-
KIT-FLAG: _-
SCC:
SERIALNO: 10001-
? 12Y-979-2160 • O-ring 2
SN: 10001-
KIT-FLAG: _-
SCC:
SERIALNO: 10001-
? 12Y-979-3232 Hose Assembly 1
SN: 10001-
KIT-FLAG: _-
SCC:
SERIALNO: 10001-
? 12Y-979-2160 • O-ring 1
SN: 10001-
KIT-FLAG: _-
SCC:
SERIALNO: 10001-
? 12Y-979-3251 Hose Assembly 1
SN: 10001-
KIT-FLAG: _-
SCC:
SERIALNO: 10001-
? 12Y-979-2150 • O-ring 2
SN: 10001-
KIT-FLAG: _-
SCC:
SERIALNO: 10001-
? 12Y-979-3261 Hose Assembly 1
SN: 10001-
KIT-FLAG: _-
SCC:
SERIALNO: 10001-
? 12Y-979-2170 • Fitting 1
SN: 10001-
KIT-FLAG: _-
SCC:
SERIALNO: 10001-
? 12Y-979-2180 • Cap 1
SN: 10001-
KIT-FLAG: _-
SCC:
SERIALNO: 10001-
? 12Y-979-2150 • O-ring 1
SN: 10001-
KIT-FLAG: _-
SCC:
SERIALNO: 10001-
? 01016-51090 Bolt 1
SN: 10001-
KIT-FLAG: _-
SCC:
SERIALNO: 10001-
? 01580-11008 Nut 1
SN: 10001-
KIT-FLAG: _-
SCC:
SERIALNO: 10001-
? 12Y-01-31381 Bracket 1
SN: 10001-
KIT-FLAG: _-
SCC:
SERIALNO: 10001-
? 01011-81220 Bolt 2
SN: 10001-
KIT-FLAG: _-
SCC:
SERIALNO: 10001-
? 01643-31232 Washer 2
SN: 10001-
KIT-FLAG: _-
SCC:
SERIALNO: 10001-
? 12Y-01-32111 Bracket 1
SN: 10001-
KIT-FLAG: _-
SCC:
SERIALNO: 10001-
? 01010-81035 Bolt 5
SN: 10001-
KIT-FLAG: _-
SCC:
SERIALNO: 10001-
? 01643-31032 Washer 5
SN: 10001-
KIT-FLAG: _-
SCC:
SERIALNO: 10001-
? 12Y-01-32591 Cover 1
SN: 10001-
KIT-FLAG: _-
SCC:
SERIALNO: 10001-
? 01010-81030 Bolt 4
SN: 10001-
KIT-FLAG: _-
SCC:
SERIALNO: 10001-
? 01643-31032 Washer 4
SN: 10001-
KIT-FLAG: _-
SCC:
SERIALNO: 10001-
? 04120-21737 V-belt 1
SN: 10001-
KIT-FLAG: _-
SCC:
SERIALNO: 10001-
? 134-54-75220 Cap 1
SN: 10001-
KIT-FLAG: _-
SCC:
SERIALNO: 10001-
? 01010-81030 Bolt 1
SN: 10001-
KIT-FLAG: _-
SCC:
SERIALNO: 10001-
? 01643-31032 Washer 1
SN: 10001-
KIT-FLAG: _-
SCC:
SERIALNO: 10001-
? 600-051-2100 Clip 1
SN: 10001-
KIT-FLAG: _-
SCC:
SERIALNO: 10001-
? 01010-81030 Bolt 1
SN: 10001-
KIT-FLAG: _-
SCC:
SERIALNO: 10001-
? 01643-31032 Washer 1
SN: 10001-
KIT-FLAG: _-
SCC:
SERIALNO: 10001-
? 12Y-979-3772 Plate 1
SN: 10001-
KIT-FLAG: _-
SCC:
SERIALNO: 10001-
? 12Y-979-3781 Cushion 1
SN: 10001-
KIT-FLAG: _-
SCC:
SERIALNO: 10001-
? 12Y-979-3791 Cushion 1
SN: 10001-
KIT-FLAG: _-
SCC:
SERIALNO: 10001-
? 01010-81030 Bolt 1
SN: 10001-
KIT-FLAG: _-
SCC:
SERIALNO: 10001-
? 01643-31032 Washer 1
SN: 10001-
KIT-FLAG: _-
SCC:
SERIALNO: 10001-
? 04434-51610 Clip 1
SN: 10001-
KIT-FLAG: _-
SCC:
SERIALNO: 10001-
? 04434-51310 Clip 1
SN: 10001-
KIT-FLAG: _-
SCC:
SERIALNO: 10001-
? 01010-81030 Bolt 1
SN: 10001-
KIT-FLAG: _-
SCC:
SERIALNO: 10001-
? 01643-31032 Washer 1
SN: 10001-
KIT-FLAG: _-
SCC:
SERIALNO: 10001-
? 04434-52110 Clip 1
SN: 10001-
KIT-FLAG: _-
SCC:
SERIALNO: 10001-
? 07095-20314 Cushion 1
SN: 10001-
KIT-FLAG: _-
SCC:
SERIALNO: 10001-
? 04434-51910 Clip 1
SN: 10001-
KIT-FLAG: _-
SCC:
SERIALNO: 10001-
? 07095-20213 Cushion 1
SN: 10001-
KIT-FLAG: _-
SCC:
SERIALNO: 10001-
? (12Y-979-1472) Tube(Cab,Air Conditioner Recirculation Air Filter and Fresh Air Filter, Receiver)
SN: -
KIT-FLAG: _-
SCC:
SERIALNO:
K0210-002029
? (12Y-979-1472) Tube(Cab,Air Conditioner Recirculation Air Filter and Fresh Air Filter, Receiver)
SN: -
KIT-FLAG: _-
SCC:
SERIALNO:
K0210-003029
? (12Y-979-1472) Tube(Cab,Air Conditioner Recirculation Air Filter and Fresh Air Filter, Receiver)
SN: -
KIT-FLAG: _-
SCC:
SERIALNO:
K0210-004029
? (12Y-979-1472) Tube(Cab,Air Conditioner Recirculation Air Filter and Fresh Air Filter, Receiver)
SN: -
KIT-FLAG: _-
SCC:
SERIALNO:
K0210-005029
? (12Y-979-1472) Tube(Cab,Air Conditioner Recirculation Air Filter and Fresh Air Filter, Receiver)
SN: -
KIT-FLAG: _-
SCC:
SERIALNO:
K0210-006029
? (12Y-979-1472) Tube(Cab,Air Conditioner Recirculation Air Filter and Fresh Air Filter, Receiver)
SN: -
KIT-FLAG: _-
SCC:
SERIALNO:
K0210-007029
? (12Y-979-1472) Tube(Cab,Air Conditioner Recirculation Air Filter and Fresh Air Filter, Receiver)
SN: -
KIT-FLAG: _-
SCC:
SERIALNO:
K0210-008029
? (12Y-979-1472) Tube(Cab,Air Conditioner Recirculation Air Filter and Fresh Air Filter, Receiver)
SN: -
KIT-FLAG: _-
SCC:
SERIALNO:
K0210-009029
? (12Y-979-1482) Tube(Cab,Air Conditioner Recirculation Air Filter and Fresh Air Filter, Receiver)
SN: -
KIT-FLAG: _-
SCC:
SERIALNO:
K0210-002029
? (12Y-979-1482) Tube(Cab,Air Conditioner Recirculation Air Filter and Fresh Air Filter, Receiver)
SN: -
KIT-FLAG: _-
SCC:
SERIALNO:
K0210-003029
? (12Y-979-1482) Tube(Cab,Air Conditioner Recirculation Air Filter and Fresh Air Filter, Receiver)
SN: -
KIT-FLAG: _-
SCC:
SERIALNO:
K0210-004029
? (12Y-979-1482) Tube(Cab,Air Conditioner Recirculation Air Filter and Fresh Air Filter, Receiver)
SN: -
KIT-FLAG: _-
SCC:
SERIALNO:
K0210-005029
? (12Y-979-1482) Tube(Cab,Air Conditioner Recirculation Air Filter and Fresh Air Filter, Receiver)
SN: -
KIT-FLAG: _-
SCC:
SERIALNO:
K0210-006029
? (12Y-979-1482) Tube(Cab,Air Conditioner Recirculation Air Filter and Fresh Air Filter, Receiver)
SN: -
KIT-FLAG: _-
SCC:
SERIALNO:
K0210-007029
? (12Y-979-1482) Tube(Cab,Air Conditioner Recirculation Air Filter and Fresh Air Filter, Receiver)
SN: -
KIT-FLAG: _-
SCC:
SERIALNO:
K0210-008029
? (12Y-979-1482) Tube(Cab,Air Conditioner Recirculation Air Filter and Fresh Air Filter, Receiver)
SN: -
KIT-FLAG: _-
SCC:
SERIALNO:
K0210-009029
