| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 58F-06-05680 | HARNESS, WIRING - HYDRAULIC BRAKE CABINET INTERNAL | 1 | ||||
| ? | PC3010 | LIGHT, DOME | 2 | ||||
| ? | 58E-06-10960 | • KIT, LENS REPLACEMENT | 1 | ||||
| ? | WB3770 | MACHINE SCREW - #10 - 24NC X 3/4" | 8 | ||||
| ? | SR8325 | SWITCH, TOGGLE | 1 | ||||
| ? | PB3324 | BOOT, SWITCH | 1 | ||||
| ? | WB3771 | NAME PLATE - SLS | 1 | ||||
| ? | MM0459 | FLAT WASHER - M6 | 4 | ||||
| ? | MM0469 | LOCKWASHER - M6 | 4 | ||||
| ? | MM0176 | NUT - M6 X 1.00 | 4 | ||||
| ? | (NSS) | BRACKET, LIGHT | 1 | ||||
| ? | 58E-06-05680 | BRACKET, LIGHT | 1 | ||||
| ? | EM8447 | PLATE, BENT | 2 | ||||
| ? | 58C-54-00440 | BRACKET | 1 | ||||
| ? | WB3098 | CLAMP, CUSHIONED - 3/8" | 1 | ||||
| ? | 58D-90-00700 | CLAMP, CUSHIONED - 7/16" | 2 | ||||
| ? | MM0605 | CAPSCREW - M10 X 1.50 X 25 | 4 | ||||
| ? | MM0178 | NUT - M10 X 1.50 | 3 | ||||
| ? | MM0461 | FLAT WASHER - M10 | 7 | ||||
| ? | MM0471 | LOCKWASHER - M10 | 4 |
