| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | WB3097 | CLAMP, CUSHIONED - 1/2" | 7 | ||||
| ? | EL7273 | SPACER | 16 | ||||
| ? | 58B-09-50000 | BRACKET | 1 | ||||
| ? | 58B-06-23810 | HARNESS, WIRING - LH GRILLE | 1 | ||||
| ? | 58B-06-23820 | HARNESS, WIRING - RH GRILLE | 1 | ||||
| ? | WB1304 | CLAMP, CUSHIONED - 9/16" | 2 | ||||
| ? | MM0178 | NUT - M10 X 1.50 | 29 | ||||
| ? | MM0461 | FLAT WASHER - M10 | 37 | ||||
| ? | MM0605 | CAPSCREW - M10 X 1.50 X 25 | 7 | ||||
| ? | 58D-90-00700 | CLAMP, CUSHIONED - 7/16" | 15 | ||||
| ? | 58B-06-60300 | BRACKET | 2 | ||||
| ? | WB3098 | CLAMP, CUSHIONED - 3/8" | 18 | ||||
| ? | MM0471 | LOCKWASHER - M10 | 36 | ||||
| ? | WB1302 | CLAMP, CUSHIONED - 5/16" | 2 | ||||
| ? | MM0604 | CAPSCREW - M10 X 1.50 X 20 | 1 | ||||
| ? | 08193-21012 | CLIP | 1 |
