| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 58B-06-23891 | HARNESS, WIRING - RH DECK | 1 | ||||
| ? | 58D-06-00831 | LIGHT, LED - AMBER | 2 | ||||
| ? | 58D-90-00700 | CLAMP, CUSHIONED - 7/16" | 4 | ||||
| ? | EG0018 | BRACKET | 1 | ||||
| ? | EK9883 | SPACER | 6 | ||||
| ? | MM0178 | NUT - M10 X 1.50 | 20 | ||||
| ? | MM0459 | FLAT WASHER - M6 | 2 | ||||
| ? | MM0469 | LOCKWASHER - M6 | 2 | ||||
| ? | MM0581 | CAPSCREW - M6 X 1.00 X 16 | 2 | ||||
| ? | MM0461 | FLAT WASHER - M10 | 20 | ||||
| ? | MM0471 | LOCKWASHER - M10 | 20 | ||||
| ? | SG3146 | GROMMET | 1 | ||||
| ? | TY8375 | SPACER | 5 | ||||
| ? | WB1300 | CLAMP, CUSHIONED - 5/8" | 1 | ||||
| ? | WB1302 | CLAMP, CUSHIONED - 5/16" | 2 | ||||
| ? | WB1305 | CLAMP, CUSHIONED - 1 1/2" | 2 | ||||
| ? | WB3092 | CLAMP, CUSHIONED - 7/8" | 1 | ||||
| ? | WB3096 | CLAMP, CUSHIONED - 1 1/4" | 9 | ||||
| ? | WB3097 | CLAMP, CUSHIONED - 1/2" | 2 | ||||
| ? | WB3098 | CLAMP, CUSHIONED - 3/8" | 2 | ||||
| ? | 58B-54-90460 | ROD, THREADED | 1 | ||||
| ? | 58F-09-01170 | WASHER, FLAT 1.000 ZINC | 2 | ||||
| ? | C1669 | CAPSCREW - 1" - 8NC X 3 1/2" | 1 | ||||
| ? | VH8186 | LOCKNUT - 1" - 8NC | 1 | ||||
| ? | C1532 | NUT - 1" - 14UNS | 3 | ||||
| ? | PB6831 | ROD END | 1 | ||||
| ? | PC0780 | MOUNT, RUBBER | 1 | ||||
| ? | ED9895 | FLAT WASHER - M24 | 2 |
