Каталог Komatsu

k-part

Номер на схеме	Каталожный номер	Название	Количество
?	58B-06-12730	PLATE, BENT	1
?	58B-06-12700	BRACKET	1
?	58B-03-10320	PLATE, BENT	1
?	58B-80-05070	BRACKET ASSEMBLY	1
?	426-06-11570	BRACKET	1
?	58B-06-12900	BRACKET	1
?	58B-06-20020	BRACKET	3
?	EM8447	PLATE, BENT	1
?	WB3855	CLAMP, CUSHIONED - 13/16"	1
?	WB3093	CLAMP, CUSHIONED - 1"	2
?	WB1304	CLAMP, CUSHIONED - 9/16"	5
?	WB3856	CLAMP, CUSHIONED - 1 1/8"	1
?	MM0604	CAPSCREW - M10 X 1.50 X 20	4
?	TY8375	SPACER	1
?	WB3098	CLAMP, CUSHIONED - 3/8"	1
?	MM0581	CAPSCREW - M6 X 1.00 X 16	7
?	MM0469	LOCKWASHER - M6	7
?	MM0459	FLAT WASHER - M6	7
?	MM0343	MACHINE SCREW - M4 X 0.7 X 16	4
?	MM0378	LOCKWASHER, EXTERNAL TOOTH - M4	4
?	MM0372	NUT - M4 X 0.7	4
?	MM0178	NUT - M10 X 1.50	6
?	MM0471	LOCKWASHER - M10	10
?	MM0461	FLAT WASHER - M10	12
?	58B-80-05860	BRACKET ASSEMBLY	1
?	58D-90-00700	CLAMP, CUSHIONED - 7/16"	1
?	MM0460	FLAT WASHER - M8	3
?	MM0617	CAPSCREW - M12 X 1.75 X 25	1
?	MM0706	FLAT WASHER, HARDENED - M16	4
?	MM0474	LOCKWASHER - M16	4
?	MM0038	CAPSCREW - M16 X 2.00 X 35	4
?	MM0462	FLAT WASHER - M12	3
?	MM0472	LOCKWASHER - M12	3
?	MM0606	CAPSCREW - M10 X 1.50 X 30	2
?	MM0616	CAPSCREW - M12 X 1.75 X 20	2
?	08038-00519	CAP, TERMINAL	3
?	WB1302	CLAMP, CUSHIONED - 5/16"	1
