| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 58E-06-11840 | BOX, EMERGENCY ENGINE SHUTDOWN | 1 | ||||
| ? | 58E-06-13190 | SWITCH, PUSH-PULL | 1 | ||||
| ? | TH9117 | GROMMET | 1 | ||||
| ? | 58B-06-21270 | HARNESS, WIRING - ENGINE SHUTDOWN | 1 | ||||
| ? | 58B-06-20020 | BRACKET | 2 | ||||
| ? | WB3098 | CLAMP, CUSHIONED - 3/8" | 5 | ||||
| ? | MM0607 | CAPSCREW - M10 X 1.50 X 35 | 2 | ||||
| ? | MM0471 | LOCKWASHER - M10 | 5 | ||||
| ? | MM0461 | FLAT WASHER - M10 | 5 | ||||
| ? | MM0605 | CAPSCREW - M10 X 1.50 X 25 | 3 | ||||
| ? | VA2828 | SWITCH, FLUSH | 1 | ||||
| ? | VA2826 | COVER, SWITCH | 1 | ||||
| ? | VN7129 | MACHINE SCREW - #6 - 32NC X 5/8" | 6 | ||||
| ? | DF4944 | LOCKWASHER - #6 | 6 | ||||
| ? | HE5125 | FLAT WASHER - #6 | 6 | ||||
| ? | PB9072 | CONDULET, SINGLE GANG | 1 | ||||
| ? | MM0358 | MACHINE SCREW - M6 X 1.00 X 16 | 2 | ||||
| ? | MM0469 | LOCKWASHER - M6 | 2 | ||||
| ? | EM7830 | HARNESS, WIRING - LADDER LIGHT JUMPER | 1 |
