| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 58B-54-62500 | BATTERY BOX | 1 | ||||
| ? | 58B-06-02580 | • CONNECTOR, FUSE HOLDER | 1 | ||||
| ? | MM0595 | • CAPSCREW - M8 X 1.25 X 30 | 8 | ||||
| ? | MM0714 | • FLAT WASHER, HARDENED - M12 | 4 | ||||
| ? | MM0470 | • LOCKWASHER - M8 | 10 | ||||
| ? | MM0460 | • FLAT WASHER - M8 | 10 | ||||
| ? | 58F-54-20910 | • PLATE | 1 | ||||
| ? | PB5993 | • COVER | 2 | ||||
| ? | MM0594 | • CAPSCREW - M8 X 1.25 X 25 | 2 | ||||
| ? | 58F-06-02901 | • CABLE, RED | 1 | ||||
| ? | MM0472 | • LOCKWASHER - M12 | 8 | ||||
| ? | MM0462 | • FLAT WASHER - M12 | 12 | ||||
| ? | 58B-06-60090 | • BUS BAR | 1 | ||||
| ? | VZ2686 | • STAND-OFF, INSULATED | 2 | ||||
| ? | TR6008 | • FLAT WASHER - 1/2" | 4 | ||||
| ? | TR5445 | • LOCKWASHER - 1/2" | 4 | ||||
| ? | MM0179 | • NUT - M12 X 1.75 | 8 | ||||
| ? | VC1387 | • CAPSCREW - 1/2" - 13NC X 1" | 2 | ||||
| ? | MM0620 | • CAPSCREW - M12 X 1.75 X 40 | 8 | ||||
| ? | MM0177 | • NUT - M8 X 1.25 | 8 | ||||
| ? | 58F-06-50520 | • RECEPTACLE, AUXILIARY START | 1 | ||||
| ? | 58F-06-50530 | • RECEPTACLE, AUXILIARY START | 1 | ||||
| ? | EJ7781 | • GASKET, RUBBER | 2 | ||||
| ? | VC6561 | • CAPSCREW - 1/2" - 13NC X 1 1/2" | 2 |
