Каталог Komatsu

k-part

Номер на схеме	Каталожный номер	Название	Количество
?	58E-06-18481	COVER, WIRE	2
?	58E-06-18391	DUCT, WIRE	2
?	58E-06-07330	COVER, WIRE	1
?	58E-06-07320	DUCT, WIRE	1
?	58E-06-10360	SCREW, FLANGE - #10 - 24NC X 3/4"	12
?	58E-06-10350	NUT, RIBBED - #10 - 24NC	12
?	PC1110	CONVERTOR, 24V TO 12V	1
?	MM0459	FLAT WASHER - M6	7
?	MM0469	LOCKWASHER - M6	6
?	MM0176	NUT - M6 X 1.00	6
?	ED4418	BRACKET	2
?	58B-06-06920	CIRCUIT BREAKER, 150A	1
?	PB8460	CIRCUIT BREAKER	1
?	MM0581	CAPSCREW - M6 X 1.00 X 16	4
?	SP8417	FLAT WASHER - 1/4"	4
?	SD5390	MACHINE SCREW - #10 - 32NF X 1"	4
?	VC5344	FLAT WASHER - #10	4
?	DC3101	LOCKWASHER - #10	4
?	58E-06-07340	PLATE, CIRCUIT	1
?	WB3479	NAME PLATE - CB60	1
?	WB3239	NAME PLATE - 12 VCN	1
?	WB3521	NAME PLATE - EMT	1
?	WB2303	NAME PLATE - GB31	1
?	TZ7377	NAME PLATE - 24VDC	1
?	58E-06-11370	TAG, PLATE	1
?	PC2644	TIMER, 2 HOUR DELAY	1
?	MM0585	CAPSCREW - M6 X 1.00 X 35	1
?	58E-06-30050	BUS BAR	3
?	58E-06-30060	COVER, BUS BAR	1
?	58E-06-30070	BUS BAR	1
?	WB3104	FLAT WASHER - M5	6
?	WB3103	LOCKWASHER - M5	6
?	MM0373	NUT - M5 X 0.8	6
?	EM8612	ROD, THREADED - 5/16"	2
?	PB7202	INSULATOR	2
?	MM0470	LOCKWASHER - M8	2
?	TD1684	NUT - 5/16" - 18NC	2
?	TV0177	FLAT WASHER - 5/16"	2
