| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 58E-06-07350 | TERMINAL BLOCK ASSEMBLY, TB21-25 | 1 | ||||
| ? | 58E-06-20730 | TERMINAL BLOCK ASSEMBLY, TB26-30 | 1 | ||||
| ? | 58E-06-20740 | TERMINAL BLOCK ASSEMBLY, TB31-35 | 1 | ||||
| ? | 58E-06-40120 | RAIL, DIN | 3 | ||||
| ? | 58E-06-18490 | COVER, WIRING | 1 | ||||
| ? | 58E-06-18470 | DUCT, WIRING | 1 | ||||
| ? | 58E-80-11960 | COVER, WIRING | 3 | ||||
| ? | 58E-06-18430 | DUCT, WIRING | 1 | ||||
| ? | 58E-80-11950 | COVER, WIRING | 1 | ||||
| ? | 58E-06-40200 | NUT, INSERT | 12 | ||||
| ? | 58E-06-10360 | SCREW, FLANGE - #10 - 24NC X 3/4" | 37 | ||||
| ? | 58E-06-04150 | RELAY - 24V, 75 AMP | 9 | ||||
| ? | WB4001 | NAME PLATE - LOW MOUNTING HEADLIGHT RELAY | 1 | ||||
| ? | WB4004 | NAME PLATE - LADDER DECK LIGHT RELAY | 1 | ||||
| ? | WB4003 | NAME PLATE - HIGH BEAM HEADLIGHT RELAY | 1 | ||||
| ? | WB4002 | NAME PLATE - HIGH MOUNTING HEADLIGHT RELAY | 1 | ||||
| ? | WB3731 | NAME PLATE - HORN RELAY | 1 | ||||
| ? | WB2835 | NAME PLATE - KEY SWITCH POWER RELAY | 1 | ||||
| ? | WB3879 | NAME PLATE - REAR BACKUP LIGHT RELAY | 1 | ||||
| ? | WB4000 | NAME PLATE - KEY CONTROL POWER RELAY | 1 | ||||
| ? | WB2836 | NAME PLATE - 12V POWER RELAY | 1 | ||||
| ? | 58E-06-18510 | COVER, WIRING | 1 | ||||
| ? | 58E-06-18460 | DUCT, WIRING | 1 | ||||
| ? | 58E-06-18550 | COVER, WIRING | 2 | ||||
| ? | 58E-06-18450 | DUCT, WIRING | 2 | ||||
| ? | 58E-80-12000 | COVER, WIRING | 4 | ||||
| ? | 58E-06-18420 | DUCT, WIRING | 1 | ||||
| ? | 58E-06-10350 | NUT, RIBBED - #10 - 24NC | 37 | ||||
| ? | 58E-06-40210 | CAPSCREW, FLANGE - 1/4" - 20NC X 3/4" | 12 |
