| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | XC2400 | SMART RIM ASSEMBLY, REAR OUTER | 1 | ||||
| ? | XC2399 | • LOCK RING ASSEMBLY - 63" (1) | 2 | ||||
| ? | XA5925 | • • RING - 63" | 1 | ||||
| ? | XA5782 | • • RETAINER | 1 | ||||
| ? | XA5783 | • • RETAINER | 1 | ||||
| ? | 01252-71225 | • • BOLT | 2 | ||||
| ? | 01252-71270 | • • BOLT | 1 | ||||
| ? | AK4791 | • BAND, BEAD SEAT - 63" | 2 | ||||
| ? | AK5178 | • RING, SIDE | 2 | ||||
| ? | WB1139 | O-RING - 63" | 2 | ||||
| ? | NOTE: (1) USE 58E-98-00330 EXPANDER TOOL. | ||||||
| ? | (QUANTITIES SHOWN ARE FOR ONE WHEEL ONLY.) | ||||||
| ? | (DO NOT MIX STANDARD RIMS & SMART RIMS.) |
