| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 58F-33-00050 | HOUSING | 1 | ||||
| ? | EF6158 | HOUSING, PISTON | 1 | ||||
| ? | 58F-33-00340 | CAP, END | 1 | ||||
| ? | EF6157 | PISTON | 1 | ||||
| ? | 58F-33-00211 | SEAL (1) | 1 | ||||
| ? | 58F-33-00221 | SEAL (1) | 1 | ||||
| ? | WA0360 | FLAT WASHER, HARDENED - 1/2" | 12 | ||||
| ? | 58F-33-00070 | CAPSCREW, 12 PT - 1/2" - 13NC X 6 1/2" | 12 | ||||
| ? | ED4300 | SPRING, BELLEVILLE | 2 | ||||
| ? | 58F-33-00030 | DISC, SEPARATOR (1)/(2) | 4 | ||||
| ? | EM8372 | DISC, FRICTION (1)/(2) | 3 | ||||
| ? | 58F-98-00070 | PIN, DOWEL (1) | 6 | ||||
| ? | WA5665 | SPRING, COMPRESSION (1) | 18 | ||||
| ? | PB7509 | SCREW, BLEEDER (1) | 1 | ||||
| ? | EF6161 | PLUG, ADAPTER (1) | 1 | ||||
| ? | VM0314 | PLUG (1) | 2 | ||||
| ? | 58F-BK-AK300 | NOTE: (1) INCLUDED IN 58F-BK-AK300 PARKING BRAKE KIT. | |||||
| ? | 58B-00-00382 | (2) INCLUDED IN 58B-00-00382 PARKING BRAKE KIT. |
