| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 58F-08-02110 | COVER ASSEMBLY | 1 | ||||
| ? | 58F-08-02120 | COVER ASSEMBLY | 1 | ||||
| ? | 58F-08-02130 | WELDMENT | 1 | ||||
| ? | 58F-08-02140 | COVER | 1 | ||||
| ? | 58F-08-02150 | ADAPTER | 1 | ||||
| ? | VE4480 | CAPSCREW - 1/4" - 20NC X 1" | 8 | ||||
| ? | BF4421 | CAPSCREW - 3/8" - 16NC X 1" | 8 | ||||
| ? | VE4489 | CAPSCREW - 1/2" - 13NC X 1 1/4" | 8 | ||||
| ? | VE4516 | WASHER | 17 | ||||
| ? | XA4233 | FLAT WASHER - 1/4" | 8 | ||||
| ? | VE4519 | FLAT WASHER - 1/2" | 8 | ||||
| ? | XA5003 | LOCKWASHER - 1/4" | 8 | ||||
| ? | VE4687 | LOCKWASHER - 3/8" | 17 | ||||
| ? | VE4699 | LOCKWASHER - 1/2" | 9 | ||||
| ? | 58F-08-02210 | HARNESS, WIRING - RTD | 1 | ||||
| ? | 58F-08-02190 | CAPSCREW - 3/8" - 16NC X 1 1/8" | 8 | ||||
| ? | VE4632 | CAPSCREW - 3/8" - 16NC X 1/2" | 1 | ||||
| ? | VE4698 | NUT - 1/2" - 13NC | 8 |
