| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | VE9591 | SPRING | 2 | ||||
| ? | 58E-98-20360 | SEAL | 1 | ||||
| ? | VE9581 | RING, PISTON | 1 | ||||
| ? | 58E-98-00470 | SLEEVE | 1 | ||||
| ? | 58E-98-00040 | RING, BACKUP | 2 | ||||
| ? | 58E-98-00020 | O-RING | 1 | ||||
| ? | 58E-98-00010 | O-RING | 1 | ||||
| ? | 58E-98-20350 | PIN | 1 | ||||
| ? | 58E-98-00030 | RING, BACKUP | 1 | ||||
| ? | 58E-98-20320 | BARREL, CYLINDER | 1 | ||||
| ? | 58E-98-20340 | PISTON | 1 | ||||
| ? | 58E-98-20330 | BALL (2) | 1 | ||||
| ? | VE9554 | PISTON SHOE ASSEMBLY | 9 | ||||
| ? | VE9574 | RING, RETAINING | 4 | ||||
| ? | VE9575 | WASHER | 2 | ||||
| ? | VE9573 | PIN | 2 | ||||
| ? | VE9572 | LINK | 1 | ||||
| ? | VE9584 | PIN | 1 | ||||
| ? | VE9564 | PIN, DOWEL | 2 | ||||
| ? | VE9559 | SADDLE | 1 | ||||
| ? | VE9539 | O-RING | 1 | ||||
| ? | VE9533 | ROLLPIN | 1 | ||||
| ? | BF2617 | ROLLPIN (1) | 4 | ||||
| ? | BF2616 | BEARING (1) | 2 | ||||
| ? | 58E-98-20300 | SWASH BLOCK W/PIN | 1 | ||||
| ? | VE9531 | BEARING, CYLINDER | 1 | ||||
| ? | VE9557 | RETAINER (2) | 1 | ||||
| ? | VE9556 | SPRING | 9 | ||||
| ? | BF2613 | NOTE: (1) INCLUDED IN BF2613 BEARING KIT. | |||||
| ? | (2) NOT SERVICED SEPARATELY. |
