| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | EK5654 | TUBE, BENT - LH OUTER FRONT | 1 | ||||
| ? | VW7882 | HOSE | 1 | ||||
| ? | WB1177 | CLAMP, T-BOLT | 16 | ||||
| ? | 58B-54-05230 | BRACKET, MOUNTING | 1 | ||||
| ? | MM0462 | FLAT WASHER - M12 | 2 | ||||
| ? | MM0616 | CAPSCREW - M12 X 1.75 X 20 | 2 | ||||
| ? | WB1179 | CLAMP, T-BOLT | 4 | ||||
| ? | EK5666 | TUBE, BENT - LH MIDDLE FRONT | 1 | ||||
| ? | PB1597 | ELBOW, RUBBER | 1 | ||||
| ? | EK5657 | TUBE, BENT - LH INNER FRONT | 1 | ||||
| ? | TX6040 | ELBOW, RUBBER - 45 DEG | 1 | ||||
| ? | EH9685 | TUBE, MIDDLE REAR - LH | 1 | ||||
| ? | 58B-54-05110 | TUBE, OUTER REAR - LH | 1 | ||||
| ? | XB9559 | TUBE, LH INNER REAR | 1 | ||||
| ? | PC1115 | HOSE, DOUBLE HUMP | 3 | ||||
| ? | EG8033 | CLAMP, DOUBLE | 2 | ||||
| ? | TD0789 | CAPSCREW - 3/8" - 16NC X 1 3/4" | 3 | ||||
| ? | HE5611 | LOCKNUT - 3/8" - 16NC | 3 | ||||
| ? | WA4726 | FLAT WASHER, HARDENED - 3/8" | 6 | ||||
| ? | WB1169 | CLAMP, T-BOLT | 9 | ||||
| ? | EH9965 | HOSE, TURBO CONNECTION | 3 | ||||
| ? | WB1178 | CLAMP, T-BOLT | 4 |
