| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | WB0377 | FITTING, ELBOW - 90 DEG | 1 | ||||
| ? | 58B-60-01070 | FITTING, STRAIGHT | 1 | ||||
| ? | MM0605 | CAPSCREW - M10 X 1.50 X 25 | 2 | ||||
| ? | WB3092 | CLAMP, CUSHIONED - 7/8" | 3 | ||||
| ? | 58F-03-00490 | SOLENOID VALVE, FAN | 1 | ||||
| ? | 58B-60-01780 | ADAPTER | 1 | ||||
| ? | 58B-60-01790 | ADAPTER | 1 | ||||
| ? | WB0501 | FITTING, ELBOW - 90 DEG | 1 | ||||
| ? | 58B-60-40100 | FITTING, STRAIGHT | 1 | ||||
| ? | WB0505 | FITTING, ELBOW - 90 DEG | 1 | ||||
| ? | WB0535 | FITTING, ELBOW - 45 DEG | 1 | ||||
| ? | 58E-03-01190 | ADAPTER, HOSE | 1 | ||||
| ? | 58E-03-01200 | VALVE, BALL | 1 | ||||
| ? | 58B-06-21921 | HARNESS, WIRING - FAN CLUTCH | 1 | ||||
| ? | MM0618 | CAPSCREW - M12 X 1.75 X 30 | 4 | ||||
| ? | MM0714 | FLAT WASHER, HARDENED - M12 | 4 | ||||
| ? | MM0713 | FLAT WASHER, HARDENED - M10 | 2 | ||||
| ? | 58E-60-02390 | FITTING, REDUCER | 1 | ||||
| ? | 58E-60-02510 | BRACKET | 1 | ||||
| ? | WB1306 | CLAMP, CUSHIONED - 2" | 1 | ||||
| ? | WB3098 | CLAMP, CUSHIONED - 3/8" | 1 | ||||
| ? | MM0606 | CAPSCREW - M10 X 1.50 X 30 | 3 | ||||
| ? | MM0461 | FLAT WASHER - M10 | 8 | ||||
| ? | MM0471 | LOCKWASHER - M10 | 4 | ||||
| ? | MM0178 | NUT - M10 X 1.50 | 4 |
