Номер на схеме	Каталожный номер	Название	Количество
?	MM0624	CAPSCREW - M12 X 1.75 X 70	6
?	58B-09-01200	JAM NUT - M12 X 1.75	6
?	58B-09-00340	ROD END, FEMALE	6
?	58B-09-00440	ROD END, FEMALE	6
?	58F-09-00410	LOCKNUT - M12 X 1.75	11
?	MM0714	FLAT WASHER, HARDENED - M12	27
?	MM0622	CAPSCREW - M12 X 1.75 X 50	5
?	EJ9909	CLAMP	6
?	58F-09-00750	ROD, THREADED - M12 X 330	1
?	58B-02-04490	ROD, THREADED - M12 X 380	1
?	58B-09-00880	ROD, THREADED - M12 X 410	1
?	58F-09-00620	ROD, THREADED - M12 X 445	1
?	58B-09-01120	ROD, THREADED - M12 X 485	1
?	58E-09-00640	ROD, THREADED - M12 X 615	1
?	TR2961	CAPSCREW - 5/8" - 11NC X 1"	4
?	VC1390	LOCKWASHER - 5/8"	4
?	TR9082	FLAT WASHER - 5/8"	4
?	TB1406	RAIN GUARD, FRONT	1
?	TB1018	RAIN GUARD, SIDE	1
?	TB1019	RAIN GUARD, SIDE	1
?	58E-54-52071	BRACKET	1
?	MM0607	CAPSCREW - M10 X 1.50 X 35	2
?	MM0471	LOCKWASHER - M10	2
?	MM0461	FLAT WASHER - M10	2
?	VC8762	CAPSCREW - 3/8" - 16NC X 1 1/2"	3
?	HE5611	LOCKNUT - 3/8" - 16NC	3
?	WA4726	FLAT WASHER, HARDENED - 3/8"	6
?	EG7576	CLAMP, DOUBLE	2
?	WB1177	CLAMP, T-BOLT	8
?	PC1115	HOSE, DOUBLE HUMP	2
?	58E-02-50070	TUBE, INTAKE	1
?	58E-02-50041	TUBE, INTAKE	1
?	WB1170	CLAMP, T-BOLT	4
?	PC0858	ELBOW, REDUCING - 90 DEG	2
?	WB1169	CLAMP, T-BOLT	2
?	58E-02-50100	CLAMP - 6"	1
?	C5768	PLUG, PIPE - 1/8"	1
?	58B-09-01300	JAM NUT - M12 X 1.75	6
