Номер на схеме	Каталожный номер	Название	Количество
?	MM0624	CAPSCREW - M12 X 1.75 X 70	5
?	58B-09-01200	JAM NUT - M12 X 1.75	5
?	58B-09-00340	ROD END, FEMALE	5
?	58B-09-00440	ROD END, FEMALE	5
?	58F-09-00410	LOCKNUT - M12 X 1.75	8
?	MM0714	FLAT WASHER, HARDENED - M12	22
?	MM0622	CAPSCREW - M12 X 1.75 X 50	5
?	EJ9909	CLAMP	5
?	58B-09-10050	ROD, THREADED - M12 X 100	2
?	58E-09-00970	ROD, THREADED - M12 X 140	1
?	58E-09-00950	ROD, THREADED - M12 X 195	1
?	58B-09-10110	ROD, THREADED - M12 X 255	1
?	WB1177	CLAMP, T-BOLT	8
?	TR2961	CAPSCREW - 5/8" - 11NC X 1"	4
?	VC1390	LOCKWASHER - 5/8"	4
?	TR9082	FLAT WASHER - 5/8"	4
?	TB1406	RAIN GUARD, FRONT	1
?	TB1018	RAIN GUARD, SIDE	1
?	TB1019	RAIN GUARD, SIDE	1
?	58E-54-30530	BRACKET	1
?	MM0604	CAPSCREW - M10 X 1.50 X 20	2
?	MM0713	FLAT WASHER, HARDENED - M10	2
?	VC8762	CAPSCREW - 3/8" - 16NC X 1 1/2"	3
?	HE5611	LOCKNUT - 3/8" - 16NC	3
?	WA4726	FLAT WASHER, HARDENED - 3/8"	6
?	EG7576	CLAMP, DOUBLE	2
?	PC1115	HOSE, DOUBLE HUMP	2
?	MM0619	CAPSCREW - M12 X 1.75 X 35	1
?	PC0858	ELBOW, REDUCING - 90 DEG	2
?	WB1169	CLAMP, T-BOLT	2
?	WB1170	CLAMP, T-BOLT	4
?	58E-02-00840	TUBE, AIR INTAKE - LH OUTER REAR	1
?	58E-02-00890	TUBE, AIR INTAKE - LH INNER REAR	1
?	C5768	PLUG, PIPE - 1/8"	1
?	58C-09-10100	PLUG	1
?	58B-09-01300	JAM NUT - M12 X 1.75	5
