Номер на схеме	Каталожный номер	Название	Количество
?	58F-02-01690	FITTING, STRAIGHT	1
?	58B-03-00560	FITTING, TEE	2
?	58B-03-00970	FITTING	4
?	58E-02-12600	FITTING, STRAIGHT	1
?	58F-02-04360	HOSE	1
?	58B-02-04690	• CLIP, SPRING	1
?	58F-02-04350	HOSE	1
?	58B-02-04690	• CLIP, SPRING	1
?	58F-03-01420	HOSE	2
?	58F-03-01520	HOSE	2
?	EL6380	ROD, THREADED	3
?	EL8326	ROD, THREADED	4
?	EK9883	SPACER	6
?	MM0471	LOCKWASHER - M10	7
?	MM0461	FLAT WASHER - M10	7
?	WB1303	CLAMP, CUSHIONED - 3/4"	1
?	EM1393	SPACER	4
?	58D-90-00700	CLAMP, CUSHIONED - 7/16"	1
?	EM1398	SPACER	1
?	WB1300	CLAMP, CUSHIONED - 5/8"	1
?	58B-06-20020	BRACKET	5
?	MM0178	NUT - M10 X 1.50	7
?	WB3093	CLAMP, CUSHIONED - 1"	8
?	WB3922	CLAMP, CUSHIONED - 11/16"	6
?	HC0908	CLAMP, WORM DRIVE	11
?	58F-03-01120	HOSE, COOLANT	1
?	58F-03-01330	HOSE, COOLANT	1
?	58F-02-02130	HOSE	1
?	58F-02-04470	HOSE, DEF RETURN	1
?	58F-02-04460	HOSE, DEF RETURN	1
?	58F-06-21151	HARNESS, WIRING - DEF SYSTEM	1
