| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 58B-02-00740 | ADAPTER | 1 | ||||
| ? | 58B-02-00611 | CAP | 1 | ||||
| ? | 58B-09-50120 | FLAT WASHER - 1/4" | 16 | ||||
| ? | 58F-02-50860 | FITTING, ELBOW - 90 DEG | 1 | ||||
| ? | 58B-02-03470 | GASKET | 2 | ||||
| ? | 58B-02-03480 | MOUNT | 2 | ||||
| ? | 58B-02-01940 | O-RING | 3 | ||||
| ? | 58B-02-51250 | SENSOR ASSEMBLY | 2 | ||||
| ? | 58B-02-00592 | VALVE, FAST FILL - DEF | 1 | ||||
| ? | 58B-02-00770 | VENT | 1 | ||||
| ? | 58B-04-00710 | • CAP, VENT | 1 | ||||
| ? | 58B-09-50130 | CAPSCREW - 1/4" - 20NC X 5/8" | 16 | ||||
| ? | 58F-04-00950 | DEF TANK | 1 | ||||
| ? | 58B-02-00921 | • COVER | 1 | ||||
| ? | 58E-02-11160 | • FITTING, STRAIGHT | 1 | ||||
| ? | 58B-02-03490 | • COVER | 2 | ||||
| ? | 58F-02-00540 | • COVER | 2 | ||||
| ? | • TANK (1) | 1 | |||||
| ? | SH7597 | • CAPSCREW - 1/4" - 20NC X 1/2" | 28 | ||||
| ? | SP8417 | • FLAT WASHER - 1/4" | 28 | ||||
| ? | VM0321 | • PLUG, O-RING | 1 | ||||
| ? | NOTE: (1) NOT SERVICED SEPARATELY. |
