| Наименование | Страница | Код страницы |
|---|---|---|
| DEF TANK ASSEMBLY 58F-04-00941 | D-026 | 94582 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 58F-02-04490 | HOSE, DEF SUPPLY | 1 | ||||
| ? | 58F-02-04470 | HOSE, DEF RETURN | 1 | ||||
| ? | 58F-02-04460 | HOSE, DEF RETURN | 1 | ||||
| ? | 58F-02-04480 | HOSE, DEF SUPPLY | 1 | ||||
| ? | 58F-09-00040 | SCREW, FLANGE BUTTON HEAD - M10 X 1.50 X 20 | 6 | ||||
| ? | WB3092 | CLAMP, CUSHIONED - 7/8" | 1 | ||||
| ? | 58E-09-00290 | WASHER - M10 | 19 | ||||
| ? | WB3093 | CLAMP, CUSHIONED - 1" | 24 | ||||
| ? | MM0604 | CAPSCREW - M10 X 1.50 X 20 | 7 | ||||
| ? | MM0461 | FLAT WASHER - M10 | 19 | ||||
| ? | MM0178 | NUT - M10 X 1.50 | 23 | ||||
| ? | 58F-04-00941 | DEF TANK ASSEMBLY (SEE INDEX) | 1 | 94582 | |||
| ? | 58B-09-00070 | STUD - M10 X 1.50 X 45 | 6 | ||||
| ? | MM0471 | LOCKWASHER - M10 | 29 | ||||
| ? | 58E-02-51550 | FLAP, RUBBER | 1 | ||||
| ? | 58E-02-51510 | COVER | 1 | ||||
| ? | 58E-02-51460 | COVER | 1 | ||||
| ? | 58E-02-51440 | COVER | 1 | ||||
| ? | 58E-02-51580 | SEAL | 1 | ||||
| ? | EM1398 | SPACER | 1 |
