| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | FINAL DRIVE ASSEMBLY (SEE FIG. P1210-001001 ) | 0 | |||||
| ? | .MOTOR ASSEMBLY (SEE FIG. P1210-001001 ) | 1 | |||||
| ? | 708-8F-32130 | SHAFT | 1 | ||||
| ? | 708-8F-12250 | BEARING | 1 | ||||
| ? | 708-7L-12140 | BEARING | 1 | ||||
| ? | 708-7L-05010 | SPACER KIT | 1 | ||||
| ? | 708-7L-12220 | • SPACER, T=1.5 MM | 1 | ||||
| ? | 708-7L-12230 | • SPACER, T=1.6 MM | 1 | ||||
| ? | 708-7L-12240 | • SPACER, T=1.7 MM | 1 | ||||
| ? | 708-7L-12250 | • SPACER, T=1.8 MM | 1 | ||||
| ? | 708-7L-12260 | • SPACER, T=1.9 MM | 1 | ||||
| ? | 708-7L-12270 | • SPACER, T=2.0 MM | 1 | ||||
| ? | 706-7G-11291 | SEAL, OIL | 1 | ||||
| ? | 708-8F-12230 | SPACER, T=3.2 MM | 1 | ||||
| ? | 04065-07225 | RING, SNAP | 1 | ||||
| ? | 708-8F-33130 | BLOCK, CYLINDER | 1 | ||||
| ? | 708-8F-33230 | PLATE, VALVE | 1 | ||||
| ? | 720-68-19610 | PIN | 1 | ||||
| ? | 708-8F-33360 | PIN | 3 | ||||
| ? | 708-7L-13140 | SEAT | 2 | ||||
| ? | 708-8F-33160 | SPRING | 1 | ||||
| ? | 04065-04818 | RING, SNAP | 1 | ||||
| ? | 708-8F-33350 | GUIDE, RETAINER | 1 | ||||
| ? | 708-2L-33350 | RETAINER, SHOE | 1 | ||||
| ? | 708-8F-33310 | PISTON SUBASSEMBLY | 9 | ||||
| ? | 708-8F-33570 | CAM, ROCKER | 1 | ||||
| ? | 708-8F-33710 | BALL | 2 | ||||
| ? | 708-8F-34310 | PISTON | 1 | ||||
| ? | 708-8F-34260 | SPRING | 1 | ||||
| ? | 708-8F-34250 | SPRING | 1 | ||||
| ? | 708-8F-35220 | PLATE | 1 | ||||
| ? | 708-8F-35230 | PLATE | 4 | ||||
| ? | 708-8F-35120 | DISC | 4 | ||||
| ? | 708-8F-35240 | PISTON, BRAKE | 1 | ||||
| ? | 708-8F-35160 | O-RING | 1 | ||||
| ? | 708-8F-35170 | RING, BACK-UP | 1 | ||||
| ? | 708-8F-35180 | O-RING | 1 | ||||
| ? | 708-8F-35190 | RING, BACK-UP | 1 | ||||
| ? | 708-8F-35150 | SPRING | 6 | ||||
| ? | 04025-00324 | PIN, SPRING | 1 |
