Номер на схеме	Каталожный номер	Название	Количество
?	58E-06-21302	HARNESS, WIRING - DEF PUMP	2
?	58E-06-21312	HARNESS, WIRING - DEF PUMP	2
?	58B-54-06480	BRACKET	2
?	WB1302	CLAMP, CUSHIONED - 5/16"	3
?	MM0178	NUT - M10 X 1.50	8
?	58B-06-20020	BRACKET	2
?	WB3922	CLAMP, CUSHIONED - 11/16"	1
?	MM0585	CAPSCREW - M6 X 1.00 X 35	8
?	MM0459	FLAT WASHER - M6	8
?	EK9883	SPACER	6
?	MM0605	CAPSCREW - M10 X 1.50 X 25	6
?	MM0594	CAPSCREW - M8 X 1.25 X 25	4
?	MM0461	FLAT WASHER - M10	16
?	MM0471	LOCKWASHER - M10	14
?	MM0712	FLAT WASHER, HARDENED - M8	4
?	MM0469	LOCKWASHER - M6	8
?	58B-02-03440	ADAPTER	1
?	58E-09-10130	ROD, THREADED	2
?	WB3093	CLAMP, CUSHIONED - 1"	8
?	58B-02-04090	DEF FILTER ASSEMBLY	2
?	58B-02-04630	• FILTER ELEMENT	1
?	58B-02-05840	HOSE, DEF SUCTION	2
?	58B-02-04690	• CLIP, SPRING	2
?	MM0470	LOCKWASHER - M8	4
?	MM0604	CAPSCREW - M10 X 1.50 X 20	2
?	58E-02-03670	HOSE, DEF SUPPLY	1
?	58E-02-03660	HOSE, DEF SUPPLY	1
?	58F-02-04350	HOSE	1
?	58B-02-04690	CLIP, SPRING	1
?	58F-02-04360	HOSE	1
?	58B-02-04690	CLIP, SPRING	1
