| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 58E-80-04280 | BRACKET | 1 | ||||
| ? | MM0605 | CAPSCREW - M10 X 1.50 X 25 | 7 | ||||
| ? | MM0471 | LOCKWASHER - M10 | 8 | ||||
| ? | MM0461 | FLAT WASHER - M10 | 13 | ||||
| ? | MM0178 | NUT - M10 X 1.50 | 5 | ||||
| ? | WB3858 | CLAMP, CUSHIONED - 1 13/16" | 11 | ||||
| ? | WB3098 | CLAMP, CUSHIONED - 3/8" | 6 | ||||
| ? | 58F-90-00320 | CLAMP, CUSHIONED - 2 5/8" | 3 | ||||
| ? | WB1196 | CLAMP, HYDRA ZORB | 1 | ||||
| ? | HA5597 | HOSE | 1 | ||||
| ? | WB0303 | FITTING, ELBOW - 45 DEG | 1 | ||||
| ? | 58F-06-05330 | HARNESS, WIRING - LH DEF FILL | 1 | ||||
| ? | 58F-02-02200 | HOSE | 1 | ||||
| ? | MM0604 | CAPSCREW - M10 X 1.50 X 20 | 1 | ||||
| ? | 58F-02-50860 | FITTING, ELBOW - 90 DEG | 1 | ||||
| ? | 58B-02-00592 | VALVE, FAST FILL - DEF | 1 | ||||
| ? | 58B-02-01940 | O-RING | 1 | ||||
| ? | TD1548 | CAPSCREW - 1/4" - 20NC X 5/8" | 6 | ||||
| ? | SP8417 | FLAT WASHER - 1/4" | 6 | ||||
| ? | 58E-02-11160 | FITTING, STRAIGHT | 1 | ||||
| ? | WA2571 | FITTING, CAP NUT | 1 | ||||
| ? | WB1302 | CLAMP, CUSHIONED - 5/16" | 1 | ||||
| ? | WB3093 | CLAMP, CUSHIONED - 1" | 1 |
