| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 21N-01-11170 | BRACKET | 2 | Field_1: BRACKET Field_2: DZCB0002- code: |
|||
| ? | 01010-82060 | BOLT | 8 | Field_1: BOLT Field_2: DZCB0002- code: |
|||
| ? | 01643-32060 | WASHER | 8 | Field_1: WASHER Field_2: DZCB0002- code: |
|||
| ? | 04020-01842 | PIN, DOWEL | 4 | Field_1: PIN, DOWEL Field_2: DZCB0002- code: |
|||
| ? | 07049-01215 | PLUG | 2 | Field_1: PLUG Field_2: DZCB0002- code: |
|||
| ? | 21T-01-11210 | COLLAR | 2 | Field_1: COLLAR Field_2: DZCB0002- code: |
|||
| ? | 21N-01-11120 | CUSHION | 4 | Field_1: CUSHION Field_2: DZCB0002- code: |
|||
| ? | 21T-01-11220 | COLLAR | 2 | Field_1: COLLAR Field_2: DZCB0002- code: |
|||
| ? | 209-01-51133 | STOPPER | 2 | Field_1: STOPPER Field_2: DZCB0002- code: |
|||
| ? | 209-01-51190 | STOPPER | 2 | Field_1: STOPPER Field_2: DZCB0002- code: |
|||
| ? | 208-01-11181 | BOLT | 2 | Field_1: BOLT Field_2: DZCB0002- code: |
|||
| ? | 01643-32460 | WASHER | 2 | Field_1: WASHER Field_2: DZCB0002- code: |
|||
| ? | 209-01-77140 | PLATE | 1 | Field_1: PLATE Field_2: DZCB0002- code: |
|||
| ? | 209-01-51210 | SPACER | 2 | Field_1: SPACER Field_2: DZCB0002- code: |
|||
| ? | 209-01-51220 | PLATE | 2 | Field_1: PLATE Field_2: DZCB0002- code: |
|||
| ? | 01010-81235 | BOLT | 8 | Field_1: BOLT Field_2: DZCB0002- code: |
|||
| ? | 01643-31232 | WASHER | 8 | Field_1: WASHER Field_2: DZCB0002- code: |
|||
| ? | 209-01-00020 | SHIM ASSEMBLY | 2 | Field_1: SHIM ASSEMBLY Field_2: DZCB0002- code: |
|||
| ? | • SHIM, T=1.0MM | 5 | Field_1: SHIM, T=1.0MM Field_2: DZCB0002- code: C1 |
||||
| ? | • SHIM, T=0.5MM | 1 | Field_1: SHIM, T=0.5MM Field_2: DZCB0002- code: C1 |
||||
| ? | 21T-01-11210 | COLLAR | 4 | Field_1: COLLAR Field_2: DZCB0002- code: |
|||
| ? | 21T-01-11150 | CUSHION | 8 | Field_1: CUSHION Field_2: DZCB0002- code: |
|||
| ? | 21T-01-11220 | COLLAR | 4 | Field_1: COLLAR Field_2: DZCB0002- code: |
|||
| ? | 209-01-51133 | STOPPER | 2 | Field_1: STOPPER Field_2: DZCB0002- code: |
|||
| ? | 209-01-51142 | STOPPER | 2 | Field_1: STOPPER Field_2: DZCB0002- code: |
|||
| ? | 21T-01-11180 | WASHER | 2 | Field_1: WASHER Field_2: DZCB0002- code: |
|||
| ? | 21T-01-11190 | WASHER | 2 | Field_1: WASHER Field_2: DZCB0002- code: |
|||
| ? | 208-01-11181 | BOLT | 4 | Field_1: BOLT Field_2: DZCB0002- code: |
|||
| ? | 01643-32460 | WASHER | 4 | Field_1: WASHER Field_2: DZCB0002- code: |
|||
| ? | 21T-01-11230 | PLATE | 2 | Field_1: PLATE Field_2: DZCB0002- code: |
