| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 207-26-21320 | CASE | 1 | Field_1: CASE Field_2: DZAU0001- code: |
|||
| ? | 07049-02430 | PLUG | 2 | Field_1: PLUG Field_2: DZAU0001- code: |
|||
| ? | 207-26-73140 | BEARING | 1 | Field_1: BEARING Field_2: DZAU0001- code: |
|||
| ? | 207-26-73150 | BEARING | 1 | Field_1: BEARING Field_2: DZAU0001- code: |
|||
| ? | 207-26-62181 | SHAFT | 1 | Field_1: SHAFT Field_2: DZAU0001- code: |
|||
| ? | 207-26-61210 | SEAL | 1 | Field_1: SEAL Field_2: DZAU0001- code: |
|||
| ? | 207-26-75140 | COVER | 1 | Field_1: COVER Field_2: DZAU0001- code: |
|||
| ? | 01010-81030 | BOLT | 12 | Field_1: BOLT Field_2: DZAU0001- code: |
|||
| ? | 01643-31032 | WASHER | 12 | Field_1: WASHER Field_2: DZAU0001- code: |
|||
| ? | 07000-15390 | O-RING | 1 | Field_1: O-RING Field_2: DZAU0001- code: |
|||
| ? | 207-26-71581 | CARRIER | 1 | Field_1: CARRIER Field_2: DZAU0001- code: |
|||
| ? | 207-26-71540 | GEAR | 4 | Field_1: GEAR Field_2: DZAU0001- code: |
|||
| ? | 206-26-71270 | BEARING | 4 | Field_1: BEARING Field_2: DZAU0001- code: |
|||
| ? | 20Y-27-21250 | WASHERЈ ?THRUST | 8 | Field_1: WASHERЈ ?THRUST Field_2: DZAU0001- code: |
|||
| ? | 20Y-26-21320 | PIN | 4 | Field_1: PIN Field_2: DZAU0001- code: |
|||
| ? | 20Y-26-21330 | PIN | 4 | Field_1: PIN Field_2: DZAU0001- code: |
|||
| ? | 207-26-54230 | PLATE | 1 | Field_1: PLATE Field_2: DZAU0001- code: |
|||
| ? | 205-32-51211 | BOLT | 1 | Field_1: BOLT Field_2: DZAU0001- code: |
|||
| ? | 207-26-71551 | GEAR,RING | 1 | Field_1: GEAR,RING Field_2: DZAU0001- code: |
|||
| ? | 01010-81645 | BOLT | 18 | Field_1: BOLT Field_2: DZAU0001- code: |
|||
| ? | 01643-31645 | WASHER | 18 | Field_1: WASHER Field_2: DZAU0001- code: |
|||
| ? | 207-26-71530 | GEAR | 1 | Field_1: GEAR Field_2: DZAU0001- code: |
|||
| ? | 207-26-71261 | PLATE | 1 | Field_1: PLATE Field_2: DZAU0001- code: |
|||
| ? | 207-26-71570 | CARRIER | 1 | Field_1: CARRIER Field_2: DZAU0001- code: |
|||
| ? | 207-26-71521 | GEAR | 3 | Field_1: GEAR Field_2: DZAU0001- code: |
|||
| ? | 22U-26-21320 | BEARING | 3 | Field_1: BEARING Field_2: DZAU0001- code: |
|||
| ? | 22U-26-21240 | WASHER | 6 | Field_1: WASHER Field_2: DZAU0001- code: |
|||
| ? | 207-26-71210 | PIN | 3 | Field_1: PIN Field_2: DZAU0001- code: |
|||
| ? | 04064-04018 | RINGЈ ?SNAP | 6 | Field_1: RINGЈ ?SNAP Field_2: DZAU0001- code: |
|||
| ? | 207-26-71250 | HOLDER | 1 | Field_1: HOLDER Field_2: DZAU0001- code: |
|||
| ? | 04260-01270 | BALL | 1 | Field_1: BALL Field_2: DZAU0001- code: |
